Bently 3500/15E 164949-01电源模块  PDF资料

1.产 品 资 料 介 绍：

中文资料：

Bently 3500/15E 164949-01 电源模块 是 Bently Nevada 3500 系列监控系统中的一部分，主要用于为系统提供可靠的电源支持。Bently Nevada 是一款广泛应用于振动监测和设备状态监测的技术品牌，3500 系列监控系统尤其在工业环境中用于机器健康监测与保护。下面是关于 3500/15E 电源模块的一些关键特点与应用信息：

主要特点：

1. 电源管理功能：

• 3500/15E 电源模块提供稳压电源，以确保系统中其他模块的稳定运行。它主要用于为 Bently Nevada 3500 系列的其他模块（如传感器信号处理模块、报警模块、显示模块等）提供稳定的直流电源。
• 该模块支持宽范围的输入电压，可以适应不同的电力环境，确保设备在不同电力条件下的稳定运行。

2. 高可靠性：

• 作为一款关键的电源模块，3500/15E 164949-01 电源模块具有高可靠性，通常用于需要持续、不间断电力供应的工业应用中。这使得它非常适合在动力设备监控和保护系统中使用，尤其是在发电厂、石油天然气、化工厂等对设备稳定性要求极高的环境。

3. 冗余设计：

• 为了提高系统的容错能力，3500 系列监控系统通常可以支持电源模块的冗余配置。这意味着如果一个电源模块出现故障，备用模块可以接管供电，确保系统的持续运行和数据不丢失。

4. 系统兼容性：

• Bently 3500/15E 电源模块与 Bently Nevada 3500 系列中的其他监控模块兼容，包括 3500/32 振动监测模块、3500/42 温度监测模块、3500/22 流量监测模块等。它是这些模块的核心组件之一，提供稳定电源以保证系统的高效运行。

5. 安装与维护：

• 电源模块通常安装在一个机架式系统中。其设计易于集成和维护，能够快速更换或升级。其模块化设计使得整个监控系统的维护变得更加简便。
• 定期检查和测试电源模块的运行状况是确保系统正常工作的一项重要任务。

6. 保护与故障报警：

• 该电源模块具有过载保护、短路保护、过温保护等多种安全特性，可以防止因电气问题引起的系统故障。
• 如果电源模块发生故障，它通常会通过系统报警通知用户或操作员进行干预。

技术规格：

• 输入电压范围：通常为 85-264 VAC 或 100-240 VDC（具体取决于配置）。
• 输出电压：通常为 24 VDC，用于为 3500 系列模块提供所需电力。
• 输出功率：足够为多个模块提供稳定的电力支持。
• 冗余配置：支持冗余电源配置，确保高可用性。
• 温度范围：支持在工业环境下的较宽工作温度范围，通常为 -40°C 到 +70°C。

英文资料：

The Bently 3500/15E 164949-01 power module is part of the Bently Nevada 3500 series monitoring system and is primarily used to provide reliable power support for the system. Bently Nevada is a technology brand widely used for vibration monitoring and equipment condition monitoring. The 3500 series monitoring system is particularly used for machine health monitoring and protection in industrial environments. Here are some key features and application information about the 3500/15E power module:

Main features:

Power management function:

The 3500/15E power module provides a regulated power supply to ensure the stable operation of other modules in the system. It is mainly used to provide stable DC power for other modules in the Bently Nevada 3500 series, such as sensor signal processing modules, alarm modules, display modules, etc.

This module supports a wide range of input voltages and can adapt to different power environments, ensuring stable operation of equipment under different power conditions.

High reliability:

As a critical power module, the 3500/15E 164949-01 power module has high reliability and is typically used in industrial applications that require continuous, uninterrupted power supply. This makes it very suitable for use in power equipment monitoring and protection systems, especially in environments such as power plants, oil and gas, chemical plants, etc. that require extremely high equipment stability.

Redundant design:

In order to improve the fault tolerance of the system, the 3500 series monitoring system usually supports redundant configuration of power modules. This means that if a power module fails, the backup module can take over the power supply, ensuring the continuous operation of the system and preventing data loss.

System compatibility:

The Bently 3500/15E power module is compatible with other monitoring modules in the Bently Nevada 3500 series, including the 3500/32 vibration monitoring module, 3500/42 temperature monitoring module, 3500/22 flow monitoring module, etc. It is one of the core components of these modules, providing stable power to ensure efficient operation of the system.

Installation and maintenance:

Power modules are typically installed in a rack mounted system. Its design is easy to integrate and maintain, and can be quickly replaced or upgraded. Its modular design makes the maintenance of the entire monitoring system easier.

Regular inspection and testing of the operation status of the power module is an important task to ensure the normal operation of the system.

Protection and fault alarm:

This power module has various safety features such as overload protection, short circuit protection, and over temperature protection, which can prevent system failures caused by electrical problems.

If the power module malfunctions, it usually notifies the user or operator to intervene through a system alarm.

Technical specifications:

Input voltage range: typically 85-264 VAC or 100-240 VDC (depending on configuration).

Output voltage: typically 24 VDC, used to provide the required power for 3500 series modules.

Output power: sufficient to provide stable power support for multiple modules.

Redundant configuration: Supports redundant power configuration to ensure high availability.

Temperature range: Supports a wide operating temperature range in industrial environments, typically from -40 ° C to+70 ° C.

2.产      品      展      示
