Marine Mas PD-5010-LCD接口模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Marine Mas PD-5010-LCD 接口模块是一种专为船舶和海洋应用设计的控制和监控设备。它通过 LCD 显示界面和接口功能，实现系统运行参数的直观显示和操作，通常用于连接船舶的各类控制设备、传感器和数据采集系统。以下是该模块的详细信息：
主要功能和特点
LCD 显示界面
- 配备高亮度 LCD 显示屏，提供实时操作数据和状态信息。
- 支持多行显示，清晰易读，可显示报警和设备参数。
接口支持
- 支持多种通信协议，用于连接船舶的控制系统和外部设备。
- 提供标准化数据接口，如 RS-232、RS-485、CAN 总线或以太网。
多功能集成
- 用于监控多个输入信号并实时处理数据。
- 提供多通道输入和输出，用于传感器、执行器和控制设备的连接。
用户友好设计
- 带有按键或触摸屏设计，方便用户设置和调节参数。
- 配备直观菜单导航，支持快速操作和配置。
坚固可靠
- 采用工业级设计，具备防振、防水和防腐蚀特性，适应恶劣的海洋环境。
- 工作温度范围广，满足船舶运行条件下的可靠性要求。
报警功能
- 内置报警系统，显示超限、故障和系统状态信息。
- 可通过接口发送报警信号至中央控制系统。
技术规格
| 参数 | 详情 |
|---|---|
| 显示类型 | LCD 显示屏，支持多行文本和图形界面 |
| 通信接口 | RS-232、RS-485、CAN 总线、以太网等 |
| 输入信号类型 | 模拟信号（电流/电压）、数字信号 |
| 输出信号类型 | 数字输出、继电器触点 |
| 工作电源 | 24V DC 或 230V AC |
| 工作温度范围 | -20°C 至 +70°C |
| 安装方式 | 面板安装或机架安装 |
| 外壳防护等级 | IP65 或更高 |
应用领域
船舶自动化
- 用于船舶发动机、推进系统的状态监控和控制。
- 集成于船舶综合监控系统，管理多设备运行参数。
海洋平台
- 用于采集和显示海洋平台关键设备的运行数据。
数据采集和控制
- 作为传感器接口模块，采集和处理环境数据，如温度、压力和液位。
报警和状态管理
- 提供船舶和海洋系统的报警信息，提升运行安全性。
英文资料：
The Marine Mas PD-5010-LCD interface module is a control and monitoring device designed specifically for ship and marine applications. It achieves intuitive display and operation of system operating parameters through LCD display interface and interface functions, and is usually used to connect various control devices, sensors, and data acquisition systems of ships. The following is the detailed information of the module:
Main functions and features
LCD display interface
Equipped with a high brightness LCD display screen, providing real-time operational data and status information.
Support multi line display, clear and easy to read, can display alarms and device parameters.
Interface support
Supports multiple communication protocols for connecting ship control systems and external devices.
Provide standardized data interfaces such as RS-232, RS-485, CAN bus, or Ethernet.
Multi functional integration
Used to monitor multiple input signals and process data in real-time.
Provide multi-channel input and output for connecting sensors, actuators, and control devices.
User friendly design
Equipped with buttons or touch screen design, it is convenient for users to set and adjust parameters.
Equipped with intuitive menu navigation, supporting quick operation and configuration.
Durable and reliable
Adopting industrial grade design, it has anti vibration, waterproof and anti-corrosion characteristics, and is suitable for harsh marine environments.
The working temperature range is wide, meeting the reliability requirements under ship operating conditions.
Alarm function
Built in alarm system, displaying information on exceeding limits, faults, and system status.
Alarm signals can be sent to the central control system through the interface.
technical specifications
Parameter details
Display type: LCD display screen, supporting multiple lines of text and graphical interface
Communication interfaces RS-232, RS-485, CAN bus, Ethernet, etc
Input signal type: analog signal (current/voltage), digital signal
Output signal type: digital output, relay contact
Working power supply 24V DC or 230V AC
Working temperature range -20 ° C to+70 ° C
Installation method: panel installation or rack installation
Shell protection level IP65 or higher
application area
Ship automation
Used for status monitoring and control of ship engines and propulsion systems.
Integrated into the ship's comprehensive monitoring system, managing the operating parameters of multiple devices.
Ocean platform
Used to collect and display operational data of key equipment on offshore platforms.
Data collection and control
As a sensor interface module, it collects and processes environmental data such as temperature, pressure, and liquid level.
Alarm and status management
Provide alarm information for ships and marine systems to enhance operational safety.
2.产 品 展 示
