ALG220/221-F或的定时问题早期模块可能导致CPU读取的%AI值不正确IC693ALG220/221-F或更早版本报告的%AI值模块修订可能不正确，并表现出不稳定的行为。应用于的输入范围内的某些电流或电压水平该模块可能导致错误报告%AI值。问题源于使用特殊的光耦合器CPU 35x/36x模块可能出现定时问题。IC693ALG220/221-G及更高版本不会出现此问题模块修订。
HONEYWELL TC-PPD011工控卡件CPU可能产生致命故障包含DOIO函数的if逻辑阻止对智能模块的调用是反复转换运行和停止模式。存储包含对DOIO功能块调用的程序逻辑可能导致CPU耗尽系统内存。这可能会发生当PLC在运行和停止模式之间转换时时代。存储硬件配置将导致系统内存释放，PLC将恢复正常运行。CPU可能产生致命故障在存储带有大配置在存储带有非常大的配置。存储逻辑可能会使情况变得更糟和配置，或通过读取请求存储期间，来自程序员或HMI的参考表数据。有关详细信息，请参阅第6页的“存储大型配置”建议。从闪存读取损坏的数据记忆可能导致看门狗超时如果从闪存中读取损坏的数据，则监视器计时器在PLC上可能会触发。这可以通过完成有效的闪存存储。CPU可能产生致命故障使用配置模块时HHP跟随门店前往耗尽用户内存的PLC当用户在存储到之后，尝试使用HHP配置模块耗尽用户内存的PLC。固件更新失败通过清除M/T和a通电写入闪存在用户按下清除键后，固件升级可能会失败通电期间，HHP上的M/T键，然后执行写入
闪光PLC上的循环电源将使升级到
CPU Restrictions and Open Issues
Subject Description
Timing Issue with ALG220/221-F or
earlier modules may result in
incorrect %AI values read by CPU
The %AI values reported by an IC693ALG220/221-F or earlier
module revision may be incorrect and exhibit erratic behavior.
Certain current or voltage levels within the input range applied to
the module can cause the %AI values to be reported incorrectly.
The problem stems from the use of particular opto-couplers that
may exhibit timing issues with CPU 35x/36x modules.
This issue does not occur with IC693ALG220/221-G and later
module revisions.
The CPU may generate a fatal fault
if logic containing a DOIO function
block call to a smart module is
repeatedly transitioned between
RUN and STOP modes.
Storing program logic that contains a call to a DOIO function block
may cause the CPU to run out of system memory. This can occur
when the PLC transitions between RUN and STOP modes several
times.
Storing the hardware configuration will cause the system memory
to be freed, and the PLC will resume normal operation.
CPU may generate a Fatal Fault
during store of folders with large
configurations
The CPU may generate a fatal fault during a store of a folder with a
very large configuration. This may be made worse by storing logic
and configuration at the same time, or by read requests for
reference table data from a programmer or HMI during the store.
See “Storing Large Configurations” on page 6 for
recommendations.
Reading corrupted data from flash
memory may cause a Watch Dog
Timeout
If corrupted data is read from flash memory, the Watch Dog Timer
on the PLC may be triggered. This can be corrected by completing
a valid flash store.
The CPU may generate a fatal fault
when configuring a module with
the HHP following a store to the
PLC that exhausts user memory
The 90-30 PLC CPU may generate a fatal fault when the user
attempts to configure a module with the HHP after a store to the
PLC that exhausts user memory.
Firmware Update fails following
power-up with Clear M/T and a
write to flash
A firmware upgrade may fail after the user presses the Clear and
M/T keys on the HHP during power-up and then performs a write to
flash. Cycling power on the PLC will enable the upgrade to
proceed.
