制作100%屏蔽电缆使用以下步骤构建100%屏蔽电缆：1.从定制电缆上剥去约5/8英寸的绝缘层，露出盾2.从任何直接插入旧型号的连接器上取下公针脚1远程基板（IC693CHS393E、IC693CHS399D或更早版本）。3、将开口环套圈置于电缆绝缘层上（图10-17）。4、将屏蔽层折叠回电缆绝缘层和套圈顶部。5.将金属罩的凸缘放在折叠护罩的顶部，并牢固夹紧引擎盖。6.测试电缆在两个连接器外壳之间的导通性。连接欧姆表在外壳之间，弯曲电缆两端。
HONEYWERLL 51309288-275工控模块
如果金属化连接器罩如果未与两端的电缆屏蔽层正确接触，则连接将在欧姆表上显示间歇性连续性。7.将金属罩电缆插入远程基板扩展端口连接器或插入GE Fanuc Y形电缆，并牢固拧紧两个螺钉。安装和拧紧螺钉将屏蔽与远程基板进行电气连接机架接地，其应依次连接至接地在“安装”一章的“基板安全”标题下进行说明接地电路图以下接线图显示了输入/输出扩展系统的接线配置电缆。提供了点到点电缆和Y形电缆的接线图。在远程基板IC693CHS393E（及更早版本）和IC693CHS399D（及更早版本）中，它是需要拆下电缆插入基板处的配套电缆的针脚1。这意味着当使用工厂制造的Y形电缆IC693CBL300时，必须断开插脚1从公端拔出，插入远程基板，然后与一起使用这些基板之一。这些基板的定制Y形电缆应使用
Making a 100% Shielded Cable
Use the following steps to build a 100% shielded cable:
1. Strip approximately 5/8 inch of insulation from your custom cable to expose the
shield.
2. Remove the male Pin 1 from any connector plugging directly into an older version
remote baseplate (IC693CHS393E, IC693CHS399D, or earlier).
3. Put split-ring ferrule over cable insulation (Figure 10-17).
4. Fold the shield back over top of the cable insulation and ferrule.
5. Place the collar of the metal hood over top of the folded shield and securely clamp
the hood.
6. Test your cable for continuity between both connector shells. Connect an ohmmeter
between the shells and flex the cable at both ends. If the metalized connector hood
is not making proper contact with the cable shield at either end, the connection will
show intermittent continuity on the ohmmeter.
7. Plug the metal hooded cable onto a remote baseplate expansion port connector or
into a GE Fanuc WYE cable and securely tighten the two screws. Installing and
tightening the screws will electrically connect the shield to the remote baseplate
frame ground, which should in turn should be connected to earth ground as
instructed in the “Installation” chapter, under the heading “Baseplate Safety
GroundingWiring Diagrams
The following wiring diagrams show the wiring configuration for I/O expansion system
cables. Wiring diagrams are provided for both point-to-point cables and Wye cables.In remote baseplates, IC693CHS393E (and earlier) and IC693CHS399D (and earlier), it is
necessary to remove pin 1 of the mating cable where the cable plugs into the baseplate.
