IC695ALG508-AA 电阻温度检测器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE Fanuc IC695ALG508-AA 是 PACSystems RX3i 系列的模拟输入模块，专门用于支持电阻温度检测器（RTD）信号的输入。该模块可直接连接 RTD 传感器，适用于工业自动化和过程控制系统中的高精度温度测量。
主要特点：
通道数量：
- 提供 8 路模拟输入通道，支持多个 RTD 传感器的同时连接。
支持的传感器类型：
- RTD 传感器：模块支持各种类型的 RTD 传感器，包括常见的 PT100、PT1000 等不同精度等级和不同温度范围的电阻温度检测器。
温度测量范围：
- 具体测量范围取决于所使用的 RTD 传感器类型，一般支持从 -200°C 到 +850°C 的温度范围，适合多种工业应用。
精度和分辨率：
- 具有高精度和高分辨率，通常为 16 位分辨率，确保温度测量的精确性。
线性化和补偿：
- 模块内置线性化功能，能够自动将 RTD 信号转换为实际的温度值。
- 同时支持导线补偿功能，可以消除由于 RTD 导线电阻造成的测量误差，确保测量的准确性。
诊断功能：
- 具备自诊断能力，支持传感器开路检测和系统故障检测，有助于及时发现和解决问题。
电气隔离：
- 提供通道与系统之间的电气隔离，增强抗干扰能力，提高系统可靠性。
配置灵活性：
- 通过 GE Fanuc 的编程工具进行参数配置，可以灵活选择 RTD 类型、输入范围以及采样速率等参数，满足不同应用需求。
技术规格：
- 型号：IC695ALG508-AA
- 输入通道：8 路 RTD 模拟输入
- 支持的 RTD 类型：PT100、PT1000、其他标准 RTD
- 测量范围：-200°C 至 +850°C（取决于 RTD 类型）
- 分辨率：16 位
- 电气隔离：提供系统与输入的隔离
- 安装方式：安装在 RX3i 机架中，支持 DIN 导轨或机架安装
- 接口：使用标准的接线端子与外部 RTD 传感器连接
英文资料：
GE Fanuc IC695ALG508-AA is an analog input module of PACSystems RX3i series, specifically designed to support the input of resistance temperature detector (RTD) signals. This module can be directly connected to RTD sensors and is suitable for high-precision temperature measurement in industrial automation and process control systems.
Main features:
Number of channels:
Provide 8 analog input channels and support simultaneous connection of multiple RTD sensors.
Supported sensor types:
RTD Sensor: The module supports various types of RTD sensors, including common PT100, PT1000 and other resistance temperature detectors with different accuracy levels and temperature ranges.
Temperature measurement range:
The specific measurement range depends on the type of RTD sensor used, and generally supports a temperature range from -200 ° C to+850 ° C, suitable for various industrial applications.
Accuracy and Resolution:
It has high precision and resolution, usually 16 bit resolution, to ensure the accuracy of temperature measurement.
Linearization and compensation:
The module has built-in linearization function, which can automatically convert RTD signals into actual temperature values.
Simultaneously supporting wire compensation function, it can eliminate measurement errors caused by RTD wire resistance and ensure measurement accuracy.
Diagnostic function:
Having self diagnostic capabilities, supporting sensor open circuit detection and system fault detection, helps to detect and solve problems in a timely manner.
Electrical isolation:
Provide electrical isolation between channels and systems, enhance anti-interference capabilities, and improve system reliability.
Configuration flexibility:
By using GE Fanuc's programming tool for parameter configuration, it is possible to flexibly select parameters such as RTD type, input range, and sampling rate to meet different application requirements.
Technical specifications:
Model: IC695ALG508-AA
Input channel: 8-channel RTD analog input
Supported RTD types: PT100, PT1000, other standard RTDs
Measurement range: -200 ° C to+850 ° C (depending on RTD type)
Resolution: 16 bits
Electrical isolation: providing isolation between the system and input
Installation method: Installed in the RX3i rack, supporting DIN rail or rack installation
Interface: Connect to external RTD sensors using standard wiring terminals
2.产 品 展 示
