Bently 3500/54 133396-01 位移监测器   PDF资料

1.产 品 资 料 介 绍：

中文资料：

Bently 3500/54 133396-01 位移监测器 是 GE Bently Nevada 公司生产的关键监测模块，专为机器状态监测和保护而设计。它属于 3500 系列的监控系统，广泛应用于大型旋转机械设备的位移监测，包括汽轮机、压缩机、发电机和泵等工业设备。

主要功能和特点：

1. 实时位移监测：

• 该位移监测器专用于对旋转机械的轴向或径向位移进行监控。它通过高精度传感器来检测设备轴的位移情况，以防止由于位移超出规定范围而造成的机械损坏或故障。
• 实时监测可以帮助预测设备潜在的失效，进行预防性维护。

2. 高精度测量：

• 3500/54 采用先进的测量技术，能够对位移进行高精度的监测。精确的位移数据可用于评估机器的运行状态，并通过系统自动触发报警或关机，避免事故发生。
• 特别适合需要高精度位移测量的应用场合，例如高转速旋转机械。

3. 多通道设计：

• 该监测器支持多个输入通道，可以同时监测多根轴的位移情况。这种多通道的设计提高了监测效率，适合用于复杂的机械设备中。
• 每个通道都可以独立配置，适应不同设备的监测需求。

4. 与 3500 系列系统集成：

• Bently 3500/54 模块是 3500 系列在线监测和保护系统的一部分，能够无缝集成到已有的 3500 系统中，与其他模块协同工作，提供全面的设备状态监控和保护。
• 该模块可以与振动监测模块、速度监测模块等配合使用，为设备提供全方位的监控。

5. 报警与保护功能：

• 该模块可以设定报警限值，当位移超过设定值时，系统会自动触发报警或启动保护动作，例如减速或关闭设备。
• 监测器具备两级报警（警告和危险）设置，能够在不同位移水平下提供及时的反馈。

6. 先进的数据处理和显示：

• 监测器支持数字处理，可以将采集到的数据进行分析处理，并通过显示终端或远程系统实时显示设备位移状态。
• 数据可以存储并用于后续的故障分析与诊断，帮助优化设备运行和维护计划。

7. 可靠性和耐用性：

• Bently 3500 系列设计用于严苛的工业环境，能够在高温、振动和其他恶劣条件下保持可靠运行。模块结构坚固，适用于长期在线监测。

英文资料：

The Bently 3500/54 133396-01 displacement monitor is a critical monitoring module produced by GE Bently Nevada, designed specifically for machine condition monitoring and protection. It belongs to the 3500 series monitoring system and is widely used for displacement monitoring of large rotating machinery equipment, including industrial equipment such as turbines, compressors, generators, and pumps.

Main functions and features:

Real time displacement monitoring:

This displacement monitor is specifically designed to monitor the axial or radial displacement of rotating machinery. It detects the displacement of the equipment axis through high-precision sensors to prevent mechanical damage or failure caused by displacement exceeding the specified range.

Real time monitoring can help predict potential equipment failures and perform preventive maintenance.

High precision measurement:

The 3500/54 adopts advanced measurement technology and is capable of high-precision monitoring of displacement. Accurate displacement data can be used to evaluate the operating status of machines and automatically trigger alarms or shutdowns through the system to avoid accidents.

Especially suitable for applications that require high-precision displacement measurement, such as high-speed rotating machinery.

Multi channel design:

This monitor supports multiple input channels and can simultaneously monitor the displacement of multiple axes. This multi-channel design improves monitoring efficiency and is suitable for use in complex mechanical equipment.

Each channel can be independently configured to meet the monitoring needs of different devices.

Integration with 3500 series systems:

The Bently 3500/54 module is part of the 3500 series online monitoring and protection system, which can be seamlessly integrated into existing 3500 systems and work in conjunction with other modules to provide comprehensive equipment status monitoring and protection.

This module can be used in conjunction with vibration monitoring module, speed monitoring module, etc. to provide comprehensive monitoring for the equipment.

Alarm and protection functions:

This module can set alarm limits. When the displacement exceeds the set value, the system will automatically trigger an alarm or initiate protective actions, such as slowing down or shutting down the equipment.

The monitor has a two-level alarm (warning and danger) setting, which can provide timely feedback at different displacement levels.

Advanced data processing and display:

The monitor supports digital processing and can analyze and process the collected data, and display the device displacement status in real-time through a display terminal or remote system.

Data can be stored and used for subsequent fault analysis and diagnosis, helping to optimize equipment operation and maintenance plans.

Reliability and Durability:

The Bently 3500 series is designed for harsh industrial environments and can maintain reliable operation under high temperatures, vibrations, and other harsh conditions. The module structure is sturdy and suitable for long-term online monitoring.
