TRICONEX 3805H 数据通信模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
TRICONEX 3805H 数据通信模块 是 Triconex 公司生产的高可靠性工业控制设备，通常用于关键任务的过程控制和安全系统中。Triconex 是专门为安全相关应用设计的冗余控制系统，广泛应用于石油天然气、化工、核电等行业。3805H 数据通信模块是 Tricon 系统中负责通信和数据传输的重要组件，确保系统的安全性和数据的实时传输。
主要功能和特点：
高可靠性冗余设计：
- 3805H 模块支持三重冗余架构（Triple Modular Redundancy, TMR），在冗余系统中确保数据通信的高可靠性和容错性。
- 三重冗余架构可以容忍单一模块故障，同时不影响系统的整体性能，确保控制系统的持续运行。
高速数据通信：
- 支持高速、实时的数据传输，能够与系统中的其他模块及外部设备进行无缝通信。
- 适合需要大数据吞吐量和低延迟的工业应用场景，保证系统对过程数据的实时监控和响应。
广泛的协议支持：
- 3805H 支持多种工业通信协议，包括 Modbus、TCP/IP 等，能够方便地与其他工业控制系统、PLC、DCS 或 SCADA 系统进行集成。
- 模块具有良好的兼容性，适合多种工业通信环境。
冗余网络支持：
- 该模块提供冗余网络通信功能，确保即使在网络故障时，系统仍能够正常运行并保证数据完整性和安全性。
- 冗余网络的设计为关键任务的应用场景提供额外的安全保障。
模块化设计：
- 3805H 模块采用模块化设计，便于安装、扩展和维护，可以根据需求灵活添加或更换模块，减少停机时间。
- 模块化设计还便于系统升级，确保控制系统的可持续发展。
系统集成和可扩展性：
- 3805H 模块可与其他 Triconex 控制模块无缝集成，例如输入输出模块、处理器模块等，构建高度可靠的过程控制系统。
- 可扩展性强，适合小型和大型系统部署，满足不同规模的工业应用需求。
诊断功能：
- 模块内置自诊断功能，能够实时监测模块和系统的运行状态，快速检测故障并发出报警，减少维护时间。
- 这种智能诊断功能有助于防止系统故障，保持高可用性和安全性。
技术规格：
- 冗余架构：三重冗余（TMR）架构
- 通信速率：支持高速数据通信，具体速率依赖于网络配置和通信协议
- 协议支持：Modbus、TCP/IP 等常用工业协议
- 网络接口：多种网络接口，支持冗余通信配置
- 诊断功能：实时故障检测和自诊断功能
- 工作温度范围：适用于严苛工业环境，通常在 -20°C 至 60°C 范围内
英文资料：
The TriconeX 3805H data communication module is a high reliability industrial control equipment produced by Triconex, commonly used in process control and safety systems for critical tasks. Triconex is a redundant control system designed specifically for safety related applications, widely used in industries such as oil and gas, chemical, and nuclear power. The 3805H data communication module is an important component responsible for communication and data transmission in the Tricon system, ensuring system security and real-time data transmission.
Main functions and features:
High reliability redundancy design:
The 3805H module supports Triple Modular Redundancy (TMR) architecture, ensuring high reliability and fault tolerance of data communication in redundant systems.
Triple redundancy architecture can tolerate single module failure without affecting the overall performance of the system to ensure the continuous operation of the control system.
High speed data communication:
Supports high-speed, real-time data transmission and seamless communication with other modules and external devices in the system.
Suitable for industrial application scenarios that require big data throughput and low latency, ensuring real-time monitoring and response of the system to process data.
Wide protocol support:
3805H supports multiple industrial communication protocols, including Modbus, TCP/IP, etc., making it easy to integrate with other industrial control systems, PLCs, DCS, or SCADA systems.
The module has good compatibility and is suitable for various industrial communication environments.
Redundant network support:
This module provides redundant network communication functionality, ensuring that the system can operate normally even in the event of network failures and guaranteeing data integrity and security.
The design of redundant networks provides additional security guarantees for critical task application scenarios.
Modular design:
The 3805H module adopts a modular design, which is easy to install, expand, and maintain. It can flexibly add or replace modules according to needs, reducing downtime.
Modular design also facilitates system upgrades and ensures the sustainable development of control systems.
System integration and scalability:
The 3805H module can be seamlessly integrated with other Triconex control modules, such as input/output modules, processor modules, etc., to build highly reliable process control systems.
Strong scalability, suitable for small and large system deployment, meeting the needs of industrial applications of different scales.
Diagnostic function:
The module has built-in self diagnostic function, which can monitor the real-time operation status of the module and system, quickly detect faults and issue alarms, and reduce maintenance time.
This intelligent diagnostic function helps prevent system failures, maintain high availability and safety.
Technical specifications:
Redundant architecture: Triple Redundancy (TMR) architecture
Communication speed: Supports high-speed data communication, the specific speed depends on network configuration and communication protocol
Protocol support: Modbus, TCP/IP and other commonly used industrial protocols
Network interface: Multiple network interfaces, supporting redundant communication configuration
Diagnostic function: real-time fault detection and self diagnosis function
Operating temperature range: Suitable for harsh industrial environments, typically within the range of -20 ° C to 60 ° C
