1398-DDM-075机器人数控模块,1398-DDM-075使用配置教程
Genius总线控制器数量最多可包括八个Genius总线控制器或增强型Genius通信模块在具有5.0版或更高版本CPU固件的Series 90-30 PLC系统中。GBC不能安装在带有GCM的系统中。总线上的输入/输出设备可以是Genius输入/输出块，或一个或多个总线中的标准Series 90-70输入/输出模块更多远程下降。一条Genius总线可以服务的输入/输出电路的总数取决于CPU中使用的输入/输出设备类型和可用内存。
1398-DDM-075机器人数控模块许多Genius输入/输出块在同一块上同时具有输入和输出。在中配置的块具有输入和输出的编程软件占用相同数量的引用在%I和%Q内存中，无论块的软件配置如何。未使用的引用不能分配给其他输入或输出，不应在应用程序中使用。状态LEDGBC正面的LED指示其工作状态，正常情况下应点亮活动OK显示GBC模块的状态。通电诊断完成后，该LED点亮完整的。COM显示Genius通信总线的状态。当总线启动时，该LED稳定亮起操作正常。对于间歇性总线错误，它会闪烁，对于发生故障的总线，它会关闭。它是当没有从PLC CPU接收到配置时，也关闭。兼容性列出了与GBC模块兼容所需的特定设备或软件版本在下面90-30系列PLCCPU:GBC模块可用于以下CPU型号：IC693CPU311K、321K、331L或更高版本，或IC693CPU313、323、340、341、350、351、352、360、363和364的任何版本。CPU固件必须是5.0版或更高版本。Logicmaster 90-30版本5.0（IC641SWP301L、304J、306F、307F）、VersaPro或需要Logic Developer PLC软件。系列六PLC要与Genius总线控制器交换全局数据，系列6总线控制器
Number of Genius Bus Controllers
Up to eight Genius Bus Controllers or Enhanced Genius Communications Modules can be included
in a Series 90-30 PLC system that has release 5.0 or later CPU firmware. A GBC cannot be
installed in a system with a GCM.
The I/O devices on a bus may be Genius I/O blocks, or standard Series 90-70 I/O modules in one or
more remote drops. The total number of I/O circuits that can be served by one Genius bus depends
on the types of I/O devices that are used and the memory available in the CPU.
Many Genius I/O blocks have both inputs and outputs on the same block. Blocks configured in the
programming software as having both inputs and outputs occupy the identical number of references
in both %I and %Q memory, regardless of the block’s software configuration. Unused references
cannot be assigned to other inputs or outputs, and should not be used in the application program.
Status LEDs
The LEDs on the front of the GBC indicate its operating status and should be on during normal
operation.
OK Shows the status of the GBC module. This LED turns on after power up diagnostics are
completed.
COM Shows the status of the Genius communications bus. This LED is on steadily when the bus
is operating properly. It blinks for intermittent bus errors and is off for a failed bus. It is
also off when no configuration has been received from the PLC CPU.
Compatibility
Specific equipment or software versions required for compatibility with the GBC module are listed
below.
