TRICONEX 3624 三重冗余控制器 PDF资料

1.产 品 资 料 介 绍：

中文资料：

TRICONEX 3624 三重冗余控制器简介

1. 概述TRICONEX 3624 是一种高可靠性的三重冗余控制器，专为安全关键型应用设计，广泛应用于石油天然气、化工、核电等行业的过程控制系统。其三重模块冗余架构 (TMR) 提供卓越的容错能力，确保系统在单一故障时仍然能够继续正常运行，极大地提高了系统的安全性和稳定性。

2. 三重冗余架构 (TMR)

• 三模块架构：TRICONEX 3624 采用三重冗余架构，即系统的所有控制、输入/输出通道、通讯路径和诊断都通过三套独立的模块进行冗余备份。在任何一个模块发生故障时，其他两个模块能够继续正常工作。
• 三取二表决：每个模块独立执行相同的控制任务，并通过“三取二”投票机制决定最终的输出结果，确保即使一个模块出现故障，也不会影响系统的整体运行。
• 在线故障检测：系统具备在线故障检测和报警功能，当某个模块发生故障时，系统会自动检测并通知维护人员，同时不影响设备的正常运行。

3. 主要功能

• 高可用性：三重冗余架构提供了极高的可用性，适用于需要 24/7 全天候不间断运行的应用场景。
• 容错设计：即使系统中的任意一个模块发生故障，整个系统仍能保持100%运行，从而保障关键过程的安全和连续性。
• 快速故障恢复：支持在线热插拔功能，故障模块可以在系统运行中更换，无需停机，提升了系统的维护效率和可靠性。
• 支持多种通讯协议：TRICONEX 3624 支持与其他控制系统（如 DCS、PLC）和上位机的通讯，常见通讯协议包括 Modbus、TCP/IP 等。
• 安全功能：该控制器通过了各种国际安全标准的认证（如 SIL 3 安全等级），适用于安全仪表系统 (SIS)。

4. 技术规格

• 型号：TRICONEX 3624
• 冗余架构：三重冗余 (TMR)
• 输入输出 (I/O) 模块：支持数字量、模拟量、HART 通讯等多种 I/O 模块
• 系统容量：支持数千个输入/输出点，具体容量取决于配置
• 工作电压：24V DC、110V AC 等多种电源选项
• 响应时间：小于 100ms，确保在发生危险时快速做出反应
• 通讯接口：Modbus、TCP/IP、Ethernet 等
• 工作环境：支持宽温设计，适合在恶劣环境中运行，工作温度范围通常在 -20°C 至 +60°C

英文资料：

Introduction to TRICONEX 3624 Triple Redundant Controller

Overview: TRICONEX 3624 is a highly reliable triple redundant controller designed for safety critical applications, widely used in process control systems in industries such as oil and gas, chemical, and nuclear power. The Triple Modular Redundancy Architecture (TMR) provides excellent fault tolerance, ensuring that the system can continue to operate normally in the event of a single failure, greatly improving the safety and stability of the system.

2. Triple Redundancy Architecture (TMR)

Three module architecture: TRICONEX 3624 adopts a triple redundancy architecture, that is, all control, input/output channels, communication paths and diagnostics of the system are redundant backup through three sets of independent modules. When any module fails, the other two modules can continue to work normally.

Two out of three voting: Each module independently executes the same control task and determines the final output result through a "two out of three" voting mechanism, ensuring that even if one module fails, it will not affect the overall operation of the system.

Online fault detection: The system has online fault detection and alarm functions. When a module fails, the system will automatically detect and notify maintenance personnel, without affecting the normal operation of the equipment.

3. Main functions

High availability: The triple redundant architecture provides extremely high availability, suitable for application scenarios that require 24/7 uninterrupted operation.

Fault tolerant design: Even if any module in the system fails, the entire system can still maintain 100% operation, ensuring the safety and continuity of critical processes.

Fast fault recovery: Supports online hot swapping function, and faulty modules can be replaced during system operation without shutting down, improving the maintenance efficiency and reliability of the system.

Supports multiple communication protocols: The TRICONEX 3624 supports communication with other control systems (such as DCS, PLC) and upper computers. Common communication protocols include Modbus, TCP/IP, etc.

Safety function: This controller has been certified according to various international safety standards (such as SIL 3 safety level) and is suitable for Safety Instrumented Systems (SIS).

4. Technical specifications

Model: TRICONEX 3624

Redundant architecture: Triple Redundancy (TMR)

Input/Output (I/O) Module: Supports various I/O modules such as digital, analog, and HART communication

System capacity: Supports thousands of input/output points, the specific capacity depends on the configuration

Working voltage: Multiple power options including 24V DC, 110V AC, etc

Response time: less than 100ms, ensuring quick response in case of danger

Communication interfaces: Modbus, TCP/IP, Ethernet, etc

Working environment: Supports wide temperature design, suitable for operation in harsh environments, with a typical working temperature range of -20 ° C to+60 ° C
