Vibro-meter GSI127电耦合模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Vibro-meter GSI127 电耦合模块是Vibro-meter公司设计的一款高性能电耦合器，广泛应用于振动监测、状态监测和故障诊断领域。此模块的设计目标是提高传感器信号的可靠性与准确性，并在工业环境中提供稳定的性能。以下是对该电耦合模块的详细介绍，包括其主要功能、技术规格和应用领域等。
主要功能
信号耦合：
- GSI127模块用于将传感器信号有效耦合到监测系统，确保信号的完整性和准确性。
频率响应：
- 提供宽频率响应，适合多种振动和声学测量需求，以捕捉广泛的信号频率。
高输入阻抗：
- 模块设计具有高输入阻抗，以降低传感器信号的损失，确保信号传输的高质量。
过载保护：
- 内置过载和短路保护功能，保护模块和连接的设备，确保系统的安全性和稳定性。
多种输出选项：
- 提供多种输出类型，以便与不同的监测系统和数据采集设备进行集成。
技术规格
输入范围：
- 适用于多种传感器，包括压电传感器和其他类型的振动传感器，确保多样化的应用兼容性。
输出信号：
- 输出信号通常为标准的电压或电流信号，具体输出类型可根据应用需求选择。
频率响应范围：
- 频率响应范围一般为0.1 Hz至100 kHz，确保捕获到广泛的振动频率。
工作温度范围：
- 可在-40°C至+70°C的环境温度下稳定工作，适合恶劣的工业环境。
电源要求：
- 通常支持24V DC供电，具有低功耗设计。
尺寸和安装：
- 模块化设计，适合标准安装方式，方便集成到现有监测系统中。
英文资料：
The Vibro meter GSI127 electrical coupling module is a high-performance electrical coupler designed by Vibro meter company, widely used in the fields of vibration monitoring, condition monitoring, and fault diagnosis. The design goal of this module is to improve the reliability and accuracy of sensor signals and provide stable performance in industrial environments. The following is a detailed introduction to the electrical coupling module, including its main functions, technical specifications, and application areas.
major function
Signal coupling:
The GSI127 module is used to effectively couple sensor signals to the monitoring system, ensuring the integrity and accuracy of the signals.
Frequency response:
Provide broadband response, suitable for various vibration and acoustic measurement needs, to capture a wide range of signal frequencies.
High input impedance:
The module design features high input impedance to reduce sensor signal loss and ensure high-quality signal transmission.
Overload protection:
Built in overload and short circuit protection functions protect modules and connected devices, ensuring the safety and stability of the system.
Multiple output options:
Provide multiple output types for integration with different monitoring systems and data acquisition devices.
technical specifications
Input range:
Suitable for various sensors, including piezoelectric sensors and other types of vibration sensors, ensuring compatibility for diverse applications.
Output signal:
The output signal is usually a standard voltage or current signal, and the specific output type can be selected according to application requirements.
Frequency response range:
The frequency response range is generally from 0.1 Hz to 100 kHz, ensuring the capture of a wide range of vibration frequencies.
Working temperature range:
It can work stably in ambient temperatures ranging from -40 ° C to+70 ° C, suitable for harsh industrial environments.
Power requirements:
It usually supports 24V DC power supply and has a low-power design.
Size and installation:
Modular design, suitable for standard installation methods, easy to integrate into existing monitoring systems.
2.产 品 展 示
