Contec PIO-32/32(98)E-F接口电路板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
CONTEC PIO-32/32(98)E-F 是一款高性能的数字输入/输出接口电路板，设计用于工业自动化、设备控制和数据采集应用。它通过 PCI 总线与计算机系统连接，提供 32 路数字输入和 32 路数字输出通道，适合于需要高通道密度的应用场景。
产品规格：
- 产品型号: PIO-32/32(98)E-F
- 制造商: CONTEC
- 输入/输出通道:
- 32路数字输入
- 32路数字输出
- 接口类型: PCI总线接口
- 输入信号电压: 12-24V DC
- 输出信号类型: TTL 电平或 24V 电平
- 输出负载电流: 最大 700mA/通道（具体取决于负载类型）
- 隔离类型: 光电隔离，提供输入和输出通道的电气隔离
- 操作系统支持: Windows 和 Linux
主要功能：
- 32路数字输入: 允许采集来自外部设备（如传感器、开关）的状态信号，实现实时监控。
- 32路数字输出: 可用于控制执行器、继电器等设备，支持多种自动化控制任务。
- 光电隔离: 提供输入和输出通道的电气隔离，防止电气噪声干扰，增加系统稳定性和安全性。
产品特点：
- 高通道密度: 提供 32 路输入和 32 路输出，适合于复杂的控制和监控应用。
- 即插即用: 支持 PCI 总线即插即用功能，安装简便，无需复杂的配置。
- 工业级设计: 具备高抗干扰能力，能够在苛刻的工业环境下稳定运行。
- 高负载能力: 输出通道可以支持较高的电流和电压，适合驱动各种工业设备。
英文资料：
The CONTEC PIO-32/32 (98) E-F is a high-performance digital input/output interface circuit board designed for industrial automation, equipment control, and data acquisition applications. It is connected to the computer system through the PCI bus, providing 32 digital input and 32 digital output channels, suitable for applications that require high channel density.
Product specifications:
Product model: PIO-32/32 (98) E-F
Manufacturer: CONTEC
Input/output channels:
32 channel digital input
32 digital outputs
Interface type: PCI bus interface
Input signal voltage: 12-24V DC
Output signal type: TTL level or 24V level
Output load current: maximum 700mA/channel (depending on load type)
Isolation type: photoelectric isolation, providing electrical isolation for input and output channels
Operating system support: Windows and Linux
Main functions:
32 channel digital input: allows for the collection of status signals from external devices such as sensors and switches, enabling real-time monitoring.
32 digital outputs: can be used to control actuators, relays, and other devices, supporting various automation control tasks.
Optoelectronic isolation: provides electrical isolation of input and output channels to prevent electrical noise interference, increase system stability and safety.
Product features:
High channel density: Provides 32 inputs and 32 outputs, suitable for complex control and monitoring applications.
Plug and play: Supports PCI bus plug and play function, easy to install, no need for complex configuration.
Industrial grade design: It has high anti-interference ability and can operate stably in harsh industrial environments.
High load capacity: The output channel can support high currents and voltages, suitable for driving various industrial equipment.
2.产 品 展 示
