1.产 品 资 料 介 绍：
中文资料：
CONTEC PIO-32/32(98)E 是一款高性能的数字输入/输出接口板，主要用于工业自动化、设备控制和数据采集。该模块通过 PCI 总线与计算机系统连接，提供 32 路数字输入和 32 路数字输出通道，适用于各种工业控制应用。
产品规格：
- 产品型号: PIO-32/32(98)E
- 制造商: CONTEC
- 输入/输出通道:
- 32路数字输入
- 32路数字输出
- 接口类型: PCI总线接口
- 输入信号电压: 12-24V DC（可配置）
- 输出信号类型: TTL 电平或 24V 电平
- 输出负载电流: 最大 700mA/通道（取决于负载类型）
- 隔离类型: 光电隔离，提供输入和输出通道的电气隔离
- 操作系统支持: Windows 和 Linux
主要功能：
- 32路数字输入: 用于采集来自外部设备（如传感器、开关）的信号，实时监控设备状态。
- 32路数字输出: 用于控制执行器、继电器等设备，支持自动化控制和信号输出。
- 光电隔离: 提供输入和输出通道之间的电气隔离，防止干扰和信号衰减。
- 高负载能力: 输出通道支持较高电流和电压，适合驱动工业设备。
产品特点：
- 高通道密度: 同时支持 32 路输入和 32 路输出，适合复杂的控制和监控任务。
- 即插即用: PCI 总线接口即插即用，方便安装和配置，简化系统集成。
- 工业级设计: 具备良好的抗干扰能力和可靠性，适合各种工业环境。
- 灵活配置: 支持不同操作系统和应用程序，适应多种自动化控制需求。
应用场景：
- 工厂自动化: 用于实时监控和控制生产线设备，如开关、传感器等。
- 设备控制: 控制各种工业设备的启停、调节等操作，提高生产效率。
- 楼宇管理: 实现对楼宇设备的自动化控制，如照明、空调系统等。
- 数据采集: 采集设备和系统的状态信息，用于分析和优化工业过程。
英文资料：
The CONTEC PIO-32/32 (98) E is a high-performance digital input/output interface board primarily used for industrial automation, equipment control, and data acquisition. This module is connected to the computer system through the PCI bus, providing 32 digital input and 32 digital output channels, suitable for various industrial control applications.
Product specifications:
Product model: PIO-32/32 (98) E
Manufacturer: CONTEC
Input/output channels:
32 channel digital input
32 digital outputs
Interface type: PCI bus interface
Input signal voltage: 12-24V DC (configurable)
Output signal type: TTL level or 24V level
Output load current: maximum 700mA/channel (depending on load type)
Isolation type: photoelectric isolation, providing electrical isolation for input and output channels
Operating system support: Windows and Linux
Main functions:
32 channel digital input: used to collect signals from external devices (such as sensors, switches) and monitor device status in real-time.
32 channel digital output: used for controlling actuators, relays, and other equipment, supporting automation control and signal output.
Optoelectronic isolation: Provides electrical isolation between input and output channels to prevent interference and signal attenuation.
High load capacity: The output channel supports high currents and voltages, making it suitable for driving industrial equipment.
Product features:
High channel density: Supports both 32 inputs and 32 outputs, suitable for complex control and monitoring tasks.
Plug and play: The PCI bus interface is plug and play, making installation and configuration convenient and simplifying system integration.
Industrial grade design: It has good anti-interference ability and reliability, suitable for various industrial environments.
Flexible configuration: Supports different operating systems and applications, adapting to various automation control needs.
Application scenarios:
Factory automation: used for real-time monitoring and control of production line equipment, such as switches, sensors, etc.
Equipment control: Control the start stop, adjustment and other operations of various industrial equipment to improve production efficiency.
Building management: Implement automated control of building equipment, such as lighting, air conditioning systems, etc.
Data collection: Collecting status information of devices and systems for analyzing and optimizing industrial processes.
2.产 品 展 示
