PM3328B-6-1-3-E模块,PIONEER MAGNETICS使用参数
仅当选定的称重传感器组合设置为时,菜单SRSF才可用分段滚动。分段滚动比例因子(SRSF)用于补偿总测量张力和当并非所有辊都由分段式称重传感器支撑时,给出总张力的估计值滚动应用。有关SRSF的计算,请参阅附录A.3分段滚动比例因子(SRSF)。3.12.2.1包裹增益调度增益调度允许在一个测量辊上使用两个不同的卷筒路径。
PM3328B-6-1-3-E模块可以设置包裹增益的两个预定义值。包裹增益1用于包裹角度1,包裹增益2用于包裹角度2。要使用的两个包络增益中的哪一个是通过数字输入信号或via选择的现场总线。对于称重传感器组合,两辊增益调度仅适用于第1辊。如果数字输入设置为“0”,或者如果Profibus设置为“0”。如果数字输入设置为“1”,或者如果Profibus设置为“1”。如果数字输入用于包络增益调度,则Profibus中的包络增益调度字段为如果数字输入用于远程零设置或设置为“关”,则控制包裹增益调度来自Profibus。使用上下键从列表中选择对象类型[ZZ]。1.StandardRoll(两个称重传感器,A和B连接)2.SingleSideA(仅称重传感器A连接)3.SingleSideB(仅连接称重传感器B)当选择单侧测量时,测量信号乘以2和在显示器和模拟输出上显示为卷筒纸张力。The menu SRSF will only be available when the selected load cell combination is set to
segmented roll.
Segmented Roll Scale Factor (SRSF) is used to compensate the total measured tension and
present an estimate of total tension when not all rolls are supported by load cells in a segmented
roll application. For calculations of SRSF, refer to Appendix A.3 Segmented Roll Scale Factor
(SRSF).
3.12.2.1 Wrap Gain Scheduling
Gain scheduling enables the use of two different web paths on one measuring roll. Two predefined values for wrap gain can be set.
Wrap gain 1 is used for wrap angle 1 and wrap gain 2 for wrap angle 2.
Which of the two wrap gains that is to be used is selected with a digital input signal or via
Profibus.
For load cell combination TwoRolls gain scheduling is available only for Roll 1.
Wrap gain parameter 1 is used if the digital input is set to “0”, or if the specified field in
Profibus is set to “0”.
Wrap gain parameter 2 is used if the digital input is set to “1”, or if the specified field in
Profibus is set to “1”.
If the digital input is used for wrap gain scheduling the wrap gain scheduling field in Profibus is
disabled.
If the digital input is used for remote zero set or set to “Off”, wrap gain scheduling is controlled
from Profibus.Use up and down keys to select type of object [ZZ] from list.
1. StandardRoll (two load cells, A and B connected)
2. SingleSideA (only load cell A connected)
3. SingleSideB (only load cell B connected)
