IS220PPROS1B通用电气卡件,IS220PPROS1B中文使用说明
执行快速设置（仅适用于一卷或两卷）快速设置引导您通过最少的步骤来设置张力电子设备。要求您回答一些问题并输入所需的值。这些选择和必须进行参数设置，以准备张力电子设备进行测量。在快速设置中仅设置有限数量的选择和参数设置。所有其他参数设置为出厂默认值。见附录A.5出厂默认设置。
IS220PPROS1B通用电气卡件快速设置可以通过两种方式完成，具体取决于包裹增益的设置方式。包裹增益可以通过选择“HangWeight”或“EnterWrapGain”来设置。?使用吊重，见第3.8.1节。?使用包裹增益，见第3.8.2节。第3.12.6节解释了悬挂重量和包裹增益。检查称重传感器信号极性这是一种检查称重传感器是否连接以提供正输出的简单方法张力电子装置的信号变化导致卷筒纸张力增加。1.用手推动，在一个负载上施加与增加的腹板张力相对应的力（尽可能靠近称重传感器）并检查显示读数是否正确积极乐观的如果显示读数为负值，则将称重传感器信号连接反向至张力电子设备。注释如果不知道力的作用方向：–以相同的力方向连接称重传感器A和B。–以相同的力方向连接称重传感器C和D。要改变称重传感器A的极性，请反转X3:1和2（A+和A-）。要改变称重传感器B的极性，请反转X3:3和4（在B+和B-）要改变称重传感器C的极性，请反转X3:5和6（C+和C-）。要改变称重传感器D的极性，请反转X3:7和8（在D+和D-）。2、在改变称重传感器极性后，检查显示屏读数是否为正值腹板张力。Performing a Fast Setup (Only for One or Two Rolls)
The fast setup guides you through a minimum number of steps to set up the tension electronics.
You are asked to answer some questions and to enter desired values. These selections and
parameter settings must be made to prepare the tension electronics for measurement.
Only a limited number of selections and parameter settings are set in fast setup. All other
parameters are set as factory default values. See Appendix A.5 Factory Default Settings.
Fast setup can be done in two ways, depending on how the wrap gain is set.
The wrap gain can be set by selecting “HangWeight” or “EnterWrapGain”.
? Using Hanging Weights, see Section 3.8.1.
? Using Wrap Gain, see Section 3.8.2.
Hanging Weights and Wrap Gain are explained in Section 3.12.6. Checking Load Cell Signal Polarity
This is a simple method to check that the load cells are connected to give a positive output
signal change from the tension electronics for increased web tension.
1. Push with your hand to apply a force corresponding to increased web tension on one load
cell at a time (as close to the load cell as possible) and check if the display reading is
positive. If the display reading is negative, invert the load cell signal connection to the
tension electronics.
NOTE
If you don’t know in which direction the force is acting:
– Connect load cells A and B with the same force direction.
– Connect load cells C and D with the same force direction.
To change the polarity of load cell A, invert X3:1 and 2 (In A+ and In A-).
To change the polarity of load cell B, invert X3:3 and 4 (In B+ and In B-).
To change the polarity of load cell C, invert X3:5 and 6 (In C+ and In C-).
