DELEM DA-53S DA-56S数控折弯机控制系统 PDF资料
1.产 品 资 料 介 绍：
中文资料：
DELEM DA-53S 和 DA-56S 是由 DELEM 公司开发的数控折弯机控制系统，专为钣金折弯机设计，提供了先进的控制功能和用户友好的操作界面。这些控制系统广泛应用于金属加工行业，特别是在需要高精度和复杂折弯操作的场合。
1. DELEM DA-53S 数控折弯机控制系统
主要特点：
- 2D 图形编程：DA-53S 支持 2D 图形编程，用户可以直接在屏幕上绘制折弯工件的形状，系统会自动计算折弯顺序和所需的工具设置。
- 多轴控制：支持多轴同步控制，通常用于 X 和 Y 轴的控制，确保折弯过程的精确性。
- 用户界面友好：配备高清彩色 TFT 显示屏，界面直观，操作简单，减少了学习和操作的复杂性。
- 角度编程和补偿：用户可以直接输入折弯角度，系统会自动进行补偿计算，确保每次折弯的精确性。
- 工具库管理：内置工具库功能，用户可以存储和管理常用的模具和工具数据，提高生产效率。
- USB 接口：支持 USB 数据导入和导出，方便程序的备份和传输。
应用领域：
- 中小型折弯机：DA-53S 适用于中小型折弯机的控制，尤其是在批量生产和中等复杂性的折弯操作中表现出色。
- 钣金加工厂：广泛应用于钣金加工厂，满足多样化的折弯需求。
2. DELEM DA-56S 数控折弯机控制系统
主要特点：
- 3D 图形编程：与 DA-53S 相比，DA-56S 提供了 3D 图形编程功能，用户可以在 3D 环境下进行编程和模拟，进一步提高编程的精确性和可视化效果。
- 高级多轴控制：支持更多轴的同步控制，适用于复杂和高要求的折弯任务，例如需要控制后挡料或其他附加轴的操作。
- 全自动折弯序列计算：系统可以自动计算最佳的折弯序列和工具设置，减少人工干预，提高生产效率。
- 集成式模拟功能：用户可以在编程阶段进行折弯模拟，验证程序的正确性，减少实际操作中的错误。
- 网络连接：支持网络连接，能够与工厂的其他系统进行数据交换，适合大规模生产和自动化管理。
- 更强大的工具管理：提供更强大的工具和材料管理功能，适合复杂工艺和多样化产品的生产。
应用领域：
- 高端折弯机：DA-56S 适用于高端折弯机的控制，特别是在需要处理复杂折弯任务的工业环境中，如汽车制造、航空航天和精密金属加工等领域。
- 大规模生产线：适合在大规模生产线中使用，特别是那些需要频繁更换工具和进行复杂操作的生产环境。
英文资料：
DELEM DA-53S and DA-56S are CNC bending machine control systems developed by DELEM company, specifically designed for sheet metal bending machines, providing advanced control functions and user-friendly interface. These control systems are widely used in the metal processing industry, especially in situations that require high precision and complex bending operations.
1. DELEM DA-53S CNC bending machine control system
Main features:
2D graphic programming: DA-53S supports 2D graphic programming, allowing users to directly draw the shape of bent workpieces on the screen. The system will automatically calculate the bending sequence and required tool settings.
Multi axis control: supports multi axis synchronous control, usually used for controlling the X and Y axes to ensure the accuracy of the bending process.
User friendly interface: Equipped with a high-definition color TFT display screen, the interface is intuitive and easy to operate, reducing the complexity of learning and operation.
Angle programming and compensation: Users can directly input the bending angle, and the system will automatically perform compensation calculations to ensure the accuracy of each bending.
Tool library management: Built in tool library function, users can store and manage commonly used mold and tool data, improving production efficiency.
USB interface: Supports USB data import and export, facilitating program backup and transfer.
Application areas:
Small and medium-sized bending machines: DA-53S is suitable for controlling small and medium-sized bending machines, especially performing well in batch production and moderately complex bending operations.
Sheet metal processing factory: widely used in sheet metal processing factories to meet diverse bending needs.
2. DELEM DA-56S CNC bending machine control system
Main features:
3D graphic programming: Compared with DA-53S, DA-56S provides 3D graphic programming functionality, allowing users to program and simulate in a 3D environment, further improving the accuracy and visualization of programming.
Advanced multi axis control: supports synchronous control of more axes, suitable for complex and high demand bending tasks, such as controlling the operation of rear stop or other additional axes.
Fully automatic bending sequence calculation: The system can automatically calculate the optimal bending sequence and tool settings, reducing manual intervention and improving production efficiency.
Integrated simulation function: Users can perform bending simulation during the programming phase to verify the correctness of the program and reduce errors in actual operation.
Network connection: Supports network connection and can exchange data with other systems in the factory, suitable for large-scale production and automation management.
More powerful tool management: Provides more powerful tool and material management functions, suitable for the production of complex processes and diversified products.
Application areas:
High end bending machine: DA-56S is suitable for controlling high-end bending machines, especially in industrial environments that require complex bending tasks, such as automotive manufacturing, aerospace, and precision metal processing.
Large scale production line: suitable for use in large-scale production lines, especially in production environments that require frequent tool changes and complex operations.
2.产 品 展 示
