HONEYWELL K4LCN-16输入特性卡件,K4LCN-16使用流程
如果智能输入/输出模块(ALG240、ALG320、ALG620、ALG630、,MDL841)或网络通信模块Genius NIU站和GNIU被命令清除其配置中不包括上述模块
后续自动配置,也不是任何位于该模块右侧。这不是存储时的问题硬件配置;这只是清晰配置的一个问题活动如果您有这些模块中的一个,并且需要使用此方法生成自动配置,
HONEYWELL K4LCN-16输入特性卡件循环功率清除配置命令完成后的GNIU。操作说明/限制:增强诊断模式当用于GMR系统的安全相关部分时,GNIU的必须启用增强诊断模式。选择是否
通过硬件启用或禁用增强诊断模式GNIU的配置选项。默认设置为禁用。什么时候
启用增强诊断模式,满足以下要求必须满足。(注意:有关增强诊断的更多信息模式在Genius NIU用户手册中提供。)系统要求机架中唯一允许的模块是电源,以及GNIU和多达四个ALG265/ALG266模块(任何允许ALG265和ALG266模块的组合)。2、所有模拟模块必须位于主机架中。3、不允许使用扩展架。4、不允许使用空IO载波。配置要求
1.GNIU的报告故障参数必须设置为启用。在里面此外,报告每个模拟模块上的故障参数必须设置为启用。2.GNIU的CPU冗余参数必须设置为GMR。3.GNIU的“BSM存在”和“BSM控制器”参数必须设置为否。4、对于除最后一个模块外的每个模块,一个模拟输入通道变为无法使用。这些未使用的通道仍计入数字GNIU将发送到Genius总线的%AI通道控制器。
If an intelligent I/O module (ALG240, ALG320, ALG620, ALG630,
MDL841) or a Network Communications Module is present in the
Genius NIU station, and the GNIU is commanded to clear its
configuration, the before-mentioned module is not included in the
subsequent auto-configuration, nor are any modules that are
located to the right of that module. This is not an issue when storing
hardware configuration; It is only an issue for the clear configuration
operation. If you have one of these modules present, and need to
generate an auto-configuration using this method, cycle power of
the GNIU after the clear configuration command completes.Operating Notes/Restrictions: Enhanced
Diagnostics Mode
When used in the safety-relevant portion of a GMR system, the GNIU’s
Enhanced Diagnostics Mode must be enabled. Select whether to
enable or disable Enhanced Diagnostics Mode via a hardware
configuration option for the GNIU. The default is disabled. When
Enhanced Diagnostics Mode is enabled, the following requirements
must be met. (Note: More information about Enhanced Diagnostics
Mode is available in the Genius NIU User’s Manual.)
System Requirements
1. The only modules allowed in the rack are the Power Supply, the
GNIU, and up to four total ALG265 / ALG266 modules (any
combination of ALG265 and ALG266 modules is allowed).
2. All of the analog modules must be located in the main rack.
3. Expansion racks are not allowed.
4. Empty IO carriers are not allowed.
Configuration Requirements
1. The GNIU's Report Faults parameter must be set to Enabled. In
addition, the Report Faults parameter on every analog module
must be set to Enabled.
2. The GNIU’s CPU Redundancy parameter must be set to GMR.
3. The GNIU’s “BSM Present” and “BSM Controller” parameters must
be set to No.
4. For each module except the last, one analog input channel becomes
unusable. These unused channels still count towards the number
of %AI channels that the GNIU will send to the Genius Bus
Controller.
