REXROTH HCS02.1E-W0054-A-03-NNNN紧凑型变频器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
REXROTH HCS02.1E-W0054-A-03-NNNN紧凑型变频器是德国博世力士乐（REXROTH）公司的一款高性能变频器产品。以下是对该产品的详细介绍：
一、产品概述
型号：HCS02.1E-W0054-A-03-NNNN
品牌：博世力士乐（REXROTH）
类型：紧凑型变频器
应用领域：工业自动化、机床、机器人、自动化生产线等需要精确控制电机速度和位置的场合。
二、主要特点
- 功率范围：
- 覆盖1.5kW至11kW的功率范围，适用于中等功率需求的应用场景。
- 电流与电压：
- 最大电流可达70A，直流电源电压范围在200V至500V之间，满足多种电源配置需求。
- 集成控制单元：
- 该变频器内置一个控制单元槽，配备多种接口，便于连接自动化环境，支持编码器系统、安全技术以及附加的数字和模拟信号等。
- 灵活的控制模式：
- 支持不同的现场总线模块，如RS232、RS485、光纤、InterBus、ProfiBus等，实现多样化的控制模式。
- 高精度与稳定性：
- 伺服控制器的各项控制指标（如稳态精度和动态性能）优于通用变频器，能够提供更精确和稳定的控制效果。
- 闭环控制系统：
- 伺服控制器直接连接旋转变压器或编码器，构成速度、位移控制闭环，提高系统的控制精度和响应速度。
英文资料：
REXROTH HCS02.1E-W0054-A-03-NNN compact frequency converter is a high-performance frequency converter product from Bosch Rexroth in Germany. The following is a detailed introduction to the product:
1、 Product Overview
Model: HCS02.1E-W0054-A-03-NNN
Brand: Bosch Rexroth
Type: Compact frequency converter
Application areas: Industrial automation, machine tools, robots, automated production lines, and other applications that require precise control of motor speed and position.
2、 Main features
Power range:
Covering a power range of 1.5kW to 11kW, suitable for applications with medium power demand.
Current and voltage:
The maximum current can reach 70A, and the DC power supply voltage range is between 200V and 500V, meeting various power configuration requirements.
Integrated control unit:
The frequency converter is equipped with a control unit slot and multiple interfaces for easy connection to automation environments. It supports encoder systems, safety technology, and additional digital and analog signals.
Flexible control mode:
Support different fieldbus modules, such as RS232, RS485, fiber optic, InterBus, ProfiBus, etc., to achieve diverse control modes.
High precision and stability:
The various control indicators of the servo controller, such as steady-state accuracy and dynamic performance, are superior to those of a general frequency converter, providing more accurate and stable control effects.
Closed loop control system:
The servo controller is directly connected to the rotary transformer or encoder to form a speed and displacement control loop, improving the control accuracy and response speed of the system.
2.产 品 展 示
