REXROTH DKC11.3-100-7-FW伺服控制器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
REXROTH DKC11.3-100-7-FW伺服控制器是德国博世力士乐（REXROTH）公司推出的一款高性能伺服控制器，该产品具备多种优越的性能特点，被广泛应用于工业自动化领域。以下是对该伺服控制器的详细介绍：
一、产品概述
型号：DKC11.3-100-7-FW
品牌：博世力士乐（REXROTH）
类型：伺服控制器
应用领域：主要用于工业自动化领域中的机床、机器人、自动化生产线等设备中。
二、主要特点
- 高精度控制：
- 通过先进的数字控制技术和高速反馈控制算法，可以实现高精度的运动控制。
- 伺服电机配备高性能的转角测量编码器，能够精确测量转子的位置和电机的转速，从而实现精准的定位和速度控制。
- 多功能性：
- 具备多种控制模式和编程方式，可适应不同的应用场景和需求。
- 可以使用不同的编程语言和开发工具进行程序开发和控制逻辑实现，提高设备的灵活性和可定制性。
- 可编程性：
- 强大的编程功能使得用户可以根据实际需求进行程序开发和修改，实现复杂的控制逻辑和算法。
- 可靠性：
- 具备强大的故障检测和故障保护功能，能够实时监测设备的运行状态，并在出现故障时及时报警和停机，保证设备的稳定运行和高效工作。
- 功率器件普遍采用以智能功率模块（IPM）为核心设计的驱动电路，内部集成了驱动电路和多种故障检测保护电路，提高了设备的可靠性和安全性。
- 设计先进：
- 伺服驱动器采用数字信号处理器（DSP）作为控制核心，实现了数字化、网络化和智能化控制。
- 整流部分通过三相全桥整流电路对输入电源进行整流，得到平稳无脉动的直流电源；逆变部分则通过SPWM信号驱动IGBT，将直流电源转换为SPWM波形以驱动伺服电机。
英文资料：
The REXROTH DKC11.3-100-7-FW servo controller is a high-performance servo controller launched by Bosch Rexroth in Germany. The product has multiple superior performance characteristics and is widely used in the field of industrial automation. The following is a detailed introduction to the servo controller:
1、 Product Overview
Model: DKC11.3-100-7-FW
Brand: Bosch Rexroth
Type: Servo Controller
Application areas: Mainly used in equipment such as machine tools, robots, and automated production lines in the field of industrial automation.
2、 Main features
High precision control:
Through advanced digital control technology and high-speed feedback control algorithms, high-precision motion control can be achieved.
The servo motor is equipped with a high-performance angle measurement encoder, which can accurately measure the position of the rotor and the speed of the motor, thereby achieving precise positioning and speed control.
Multifunctionality:
Having multiple control modes and programming methods, it can adapt to different application scenarios and requirements.
Different programming languages and development tools can be used for program development and control logic implementation, improving the flexibility and customizability of devices.
Programmability:
The powerful programming capabilities enable users to develop and modify programs according to their actual needs, implementing complex control logic and algorithms.
Reliability:
Equipped with powerful fault detection and protection functions, it can monitor the operating status of equipment in real time, and promptly alarm and shut down in case of faults, ensuring the stable operation and efficient work of the equipment.
Power devices commonly use drive circuits designed with intelligent power modules (IPM) as the core, which integrate drive circuits and various fault detection and protection circuits internally, improving the reliability and safety of the equipment.
Advanced design:
The servo drive adopts a digital signal processor (DSP) as the control core, achieving digital, networked, and intelligent control.
The rectification part rectifies the input power supply through a three-phase full bridge rectification circuit to obtain a stable and ripple free DC power supply; The inverter part drives the IGBT through SPWM signal, converting the DC power supply into SPWM waveform to drive the servo motor.
2.产 品 展 示
3.其他产品
KOLLMORGEN CB06561 PRD-B040SSLZ-62 伺服驱动器
350-027750-746001P control pulse card
D20 EME 10BASE-T digital quantity control module
5.更多库存型号
| PMB31B-00200-02 | AMAT 0110-00001 | 57160001-KX DSDO 131 |
| PMB31D-10114-02 | AMAT 0100-13011 | 57160001-LF DSTD 133 |
| PMB33E-10201-02 | AMAT 0100-20241 | 57160001-LL DSDI 307 |
| PMB33F-00201-03 | AMAT 0100-09161 | 57160001-MA DSTX 120 |
| PMB31B-20201-01 | AMAT 0100-76014 | 57160001-NB DSTD 115 |
| PMB33C-20101-02 | AMAT 0100-20164 | 57160001-NF DSDO 115 |
| PMB33C-10201-02 | AMAT 129-0202 | 57160001-NL DSTD 301 |
