REXROTH HDS02.2-W040N-HS12-01-FW 伺服驱动器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
REXROTH HDS02.2-W040N-HS12-01-FW 是一款高性能的伺服驱动器，广泛应用于工业自动化和运动控制系统。该伺服驱动器具备高动态响应和精确的运动控制能力，适合各种复杂的自动化任务。
主要特点：
高动态性能：
- 提供快速的响应速度，适用于需要高精度和高动态性能的应用场景，如数控机床和工业机器人。
多种控制模式：
- 支持多种控制模式，包括位置控制、速度控制和扭矩控制，能够满足不同的应用需求。
灵活的模块化设计：
- 模块化设计使得驱动器可以根据具体应用进行灵活配置和扩展，便于维护和升级。
丰富的通讯接口：
- 配备多种通讯接口，如Profibus、CANopen等，便于与其他工业控制系统集成。
内置安全功能：
- 包含如安全扭矩关闭（STO）等安全功能，确保系统在紧急情况下的安全操作。
集成的制动功能：
- 内置制动模块，确保伺服电机在断电或停止时能够安全地制动。
技术规格：
- 型号: HDS02.2-W040N-HS12-01-FW
- 电源输入: 支持工业标准电源输入（具体电压规格需参考产品手册）
- 输出功率: 40A，适用于中功率的伺服电机
- 控制模式: 支持位置、速度和扭矩控制
- 通讯接口: 支持多种工业通讯协议，如Profibus、CANopen等
- 制动模块: 内置制动功能，确保安全制动
- 冷却方式: 强制风冷，确保驱动器在高负载下的稳定运行
- 安装方式: 适用于机柜安装，便于集成到现有控制系统中
应用领域：
- 工业自动化: 用于生产线的自动化设备中，如装配机械、搬运机器人等。
- 数控机床: 在数控机床中用于精确控制电机的运动，实现高精度加工。
- 纺织机械: 在纺织设备中用于控制纺织品加工的运动和速度。
- 包装设备: 控制包装机械的运动，确保包装过程的高速和精确。
英文资料：
REXROTH HDS02.2-W040N-HS12-01-FW is a high-performance servo drive widely used in industrial automation and motion control systems. This servo drive has high dynamic response and precise motion control capabilities, making it suitable for various complex automation tasks.
Main features:
High dynamic performance:
Provide fast response speed, suitable for application scenarios that require high precision and high dynamic performance, such as CNC machine tools and industrial robots.
Multiple control modes:
Supports multiple control modes, including position control, speed control, and torque control, to meet different application requirements.
Flexible modular design:
Modular design allows drivers to be flexibly configured and expanded according to specific applications, making it easy to maintain and upgrade.
Rich communication interfaces:
Equipped with multiple communication interfaces, such as Profibus, CANopen, etc., for easy integration with other industrial control systems.
Built in security features:
Contains safety functions such as Safe Torque Off (STO) to ensure safe operation of the system in emergency situations.
Integrated braking function:
Built in braking module ensures that the servo motor can brake safely when powered off or stopped.
Technical specifications:
Model: HDS02.2-W040N-HS12-01-FW
Power input: Supports industrial standard power input (specific voltage specifications need to refer to the product manual)
Output power: 40A, suitable for medium power servo motors
Control mode: Supports position, speed, and torque control
Communication interface: Supports multiple industrial communication protocols, such as Profibus, CANopen, etc
Braking module: Built in braking function to ensure safe braking
Cooling method: forced air cooling to ensure stable operation of the drive under high loads
Installation method: Suitable for cabinet installation, easy to integrate into existing control systems
Application areas:
Industrial automation: used in automated equipment for production lines, such as assembly machinery, handling robots, etc.
Numerical Control Machine Tool: Used in numerical control machine tools to precisely control the motion of motors and achieve high-precision machining.
Textile machinery: Used in textile equipment to control the motion and speed of textile processing.
Packaging equipment: Control the movement of packaging machinery to ensure high-speed and precise packaging process.
2.产 品 展 示
