369B1859G0022 电流互感器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
369B1859G0022 是一种电流互感器，通常用于电力系统中的电流测量和保护。电流互感器（CT）是一种将高电流转换为较小、可管理的电流信号的设备，方便测量、保护和控制系统的集成。
主要特点和功能
电流转换：
- 369B1859G0022 将高电流（如主电流）转换为较低的标准电流值，通常是 1A 或 5A。这个低电流值可以安全地输入到测量仪器、保护设备或控制系统中。
测量和监控：
- 用于电力系统中以监控电流的流量，确保系统运行在安全范围内。可以与电流表、保护继电器和其他测量设备配合使用。
保护功能：
- 在电力系统发生故障（如过电流）时，电流互感器能提供准确的电流信号，帮助保护设备进行断电或报警处理，防止设备损坏或电力系统故障扩大。
绝缘和安全：
- 设计有良好的绝缘性能，以确保高电压环境下的安全操作。防止高电流对测量设备或人员造成危险。
高精度：
- 提供高精度的电流测量，确保数据准确性和系统的可靠运行。
技术规格（示例）
- 额定电流：通常会有额定 primary 电流值，如 100A、200A、500A 等，以及转换后的 secondary 电流值，如 1A、5A。
- 额定比率：转换比率，例如 1000:5，表示 primary 电流为 1000A 时，secondary 电流为 5A。
- 精度等级：通常为 0.1、0.2、0.5 级，表示测量精度。
- 绝缘等级：电流互感器的绝缘等级，如 Class A 或 Class B，以适应不同的工作环境。
- 频率响应：能够测量的频率范围，通常与电力系统的频率（50Hz 或 60Hz）一致。
- 外形和安装：包括尺寸、安装方式（如环形、穿心式），适应不同的安装需求。
英文资料：
369B1859G0022 is a current transformer commonly used for current measurement and protection in power systems. A current transformer (CT) is a device that converts high currents into smaller, manageable current signals, facilitating the integration of measurement, protection, and control systems.
Main features and functions
Current conversion:
369B1859G0022 converts high currents (such as main currents) into lower standard current values, typically 1A or 5A. This low current value can be safely input into measuring instruments, protective equipment, or control systems.
Measurement and monitoring:
Used in power systems to monitor the flow of current and ensure that the system operates within a safe range. Can be used in conjunction with ammeters, protective relays, and other measuring devices.
Protection function:
When a fault occurs in the power system (such as overcurrent), current transformers can provide accurate current signals to help protect equipment from power outages or alarm processing, preventing equipment damage or the expansion of power system faults.
Insulation and safety:
The design has good insulation performance to ensure safe operation in high voltage environments. Prevent high current from causing danger to measuring equipment or personnel.
high-precision:
Provide high-precision current measurement to ensure data accuracy and reliable system operation.
Technical specifications (example)
Rated current: There are usually rated primary current values, such as 100A, 200A, 500A, etc., as well as converted secondary current values, such as 1A, 5A.
Rated ratio: Conversion ratio, for example 1000:5, indicates that when the primary current is 1000A, the secondary current is 5A.
Accuracy level: usually 0.1, 0.2, 0.5, indicating measurement accuracy.
Insulation level: The insulation level of current transformers, such as Class A or Class B, to adapt to different working environments.
Frequency response: The frequency range that can be measured, usually consistent with the frequency of the power system (50Hz or 60Hz).
Appearance and installation: including dimensions, installation methods (such as circular and through type), to meet different installation requirements.
