Bently 3500/93 135785-02C 系统显示器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Bently Nevada 3500/93 135785-02C 系统显示器是 3500 系列机械保护和状态监测系统中的一部分，专用于工业环境下的振动监测和诊断应用。该模块作为系统显示器，主要用于提供系统状态的可视化显示，帮助用户监控和诊断设备运行状况。
主要特点
实时数据显示: 3500/93 系统显示器能够实时显示来自 3500 系列监测模块的数据，包括振动、轴位移、转速等关键参数。这有助于操作人员在现场实时监控设备的运行状态。
多种显示模式: 该显示器支持多种数据显示模式，如趋势图、条形图、数值显示等，用户可以根据需要选择最合适的显示方式。
用户界面: 提供友好的用户界面，支持多语言显示，操作简便，易于理解和使用。用户可以通过前面板的按钮和菜单系统来导航和配置显示内容。
数据存储与检索: 该显示器具有一定的历史数据存储能力，可以存储一段时间内的关键参数变化，方便后续的故障分析和趋势预测。
模块化设计: 3500/93 系统显示器作为 3500 系列的一部分，可以与其他 3500 系列模块无缝集成，确保整个系统的兼容性和扩展性。
应用领域
旋转机械保护: 广泛应用于石油、天然气、电力、化工等行业的旋转机械（如涡轮机、压缩机、泵等）监测，帮助防止机械故障，减少意外停机时间。
振动监测: 通过实时显示振动数据，帮助维护人员快速识别设备的异常状态，从而采取预防性维护措施，延长设备的使用寿命。
工厂自动化: 在工厂自动化系统中，作为监测系统的一部分，实时监控关键设备的运行状态，确保生产过程的安全性和可靠性。
技术规格
显示屏类型: 通常为 LCD 或 LED 显示屏，支持高亮度和宽视角显示。
分辨率: 高分辨率显示，能够清晰显示复杂的图表和数据。
通信接口: 支持与 3500 系列其他模块的通信，通常通过内部总线或专用接口实现数据传输。
电源需求: 通常为 24VDC 或通过背板供电，功耗较低。
尺寸与安装: 模块化设计，符合 3500 系列标准机架尺寸，易于安装和维护。
英文资料：
The Bently Nevada 3500/93 135785-02C system monitor is part of the 3500 series mechanical protection and condition monitoring system, specifically designed for vibration monitoring and diagnostic applications in industrial environments. This module serves as a system display, mainly used to provide visual display of system status, helping users monitor and diagnose equipment operation status.
main features
Real time data display: The 3500/93 system monitor can display real-time data from the 3500 series monitoring modules, including key parameters such as vibration, shaft displacement, and speed. This helps operators to monitor the real-time operation status of the equipment on site.
Multiple display modes: This monitor supports multiple data display modes, such as trend charts, bar charts, numerical displays, etc. Users can choose the most suitable display mode according to their needs.
User Interface: Provides a user-friendly interface, supports multilingual display, is easy to operate, and is easy to understand and use. Users can navigate and configure display content through the buttons and menu system on the front panel.
Data storage and retrieval: This display has a certain historical data storage capability, which can store key parameter changes over a period of time, facilitating subsequent fault analysis and trend prediction.
Modular design: As part of the 3500 series, the 3500/93 system monitor can seamlessly integrate with other 3500 series modules, ensuring compatibility and scalability of the entire system.
application area
Rotating machinery protection: widely used for monitoring rotating machinery (such as turbines, compressors, pumps, etc.) in industries such as petroleum, natural gas, power, and chemical, helping to prevent mechanical failures and reduce unexpected downtime.
Vibration monitoring: By displaying real-time vibration data, maintenance personnel can quickly identify abnormal states of equipment, take preventive maintenance measures, and extend the service life of equipment.
Factory automation: In the factory automation system, as part of the monitoring system, real-time monitoring of the operating status of key equipment is carried out to ensure the safety and reliability of the production process.
technical specifications
Display screen type: usually LCD or LED display screen, supporting high brightness and wide viewing angle display.
Resolution: High resolution display, capable of clearly displaying complex charts and data.
Communication interface: Supports communication with other modules in the 3500 series, usually through internal buses or dedicated interfaces for data transmission.
Power requirement: Usually 24VDC or powered through the backplane, with low power consumption.
Size and Installation: Modular design, compliant with 3500 series standard rack dimensions, easy to install and maintain.
2.产 品 展 示
