SBC486DX66 网络计算机模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
SBC486DX66 是一款基于 Intel 486DX66 处理器的单板计算机（Single Board Computer, SBC），通常用于嵌入式系统和工业应用中的网络计算。这种单板计算机模块提供了计算和接口功能，适用于需要稳定性和耐用性的工业环境。
主要特点
处理器: 配备 Intel 486DX66 处理器，具有 66 MHz 的时钟速度。这款处理器在当时的计算能力较强，适用于嵌入式应用。
内存: 通常配备板载内存和扩展插槽，可以支持多种存储需求。内存容量根据具体型号可能有所不同，通常为几兆字节到几十兆字节。
存储接口: 支持 IDE、SCSI 或其他存储接口，用于连接硬盘或其他存储设备。
网络接口: 配备网络接口卡（NIC），支持以太网连接，允许模块用于联网应用。
I/O 接口: 提供多种输入/输出接口，包括串口（COM）、并口（LPT）、PS/2 接口、VGA 接口等，用于连接外围设备。
操作系统支持: 通常支持 DOS、Windows 3.x、Windows 95、Windows NT 等操作系统，还可以运行某些实时操作系统（RTOS）或嵌入式 Linux 版本。
应用领域
工业自动化: 作为工业控制系统的核心组件，用于实时数据处理和控制任务。
嵌入式系统: 应用于各种嵌入式设备中，如网络终端、数据采集系统、工业计算机等。
网络计算: 用于早期的网络计算设备，提供基础的计算和网络功能。
工厂自动化: 在工厂自动化系统中用作主控制器，处理各种自动化设备的数据和控制指令。
技术规格
处理器: Intel 486DX66 处理器，66 MHz 时钟速度。
内存: 通常支持 SIMM 内存模块，内存容量视具体型号而定。
存储: 支持 IDE、SCSI 等存储设备，通常有一个或多个硬盘接口。
扩展插槽: 提供 ISA、PCI 等扩展插槽，用于添加额外的功能卡。
电源要求: 通常为标准的 AT 电源或特定的工业电源输入。
尺寸: 单板计算机的物理尺寸通常为标准的 3U 或 6U 工业机架安装大小。
英文资料：
SBC486DX66 is a Single Board Computer (SBC) based on the Intel 486DX66 processor, commonly used for network computing in embedded systems and industrial applications. This single board computer module provides computing and interface functions, suitable for industrial environments that require stability and durability.
main features
Processor: Equipped with Intel 486DX66 processor with a clock speed of 66 MHz. This processor had strong computing power at the time and was suitable for embedded applications.
Memory: Typically equipped with onboard memory and expansion slots, it can support multiple storage requirements. The memory capacity may vary depending on the specific model, typically ranging from a few megabytes to several tens of megabytes.
Storage interface: Supports IDE, SCSI, or other storage interfaces for connecting hard drives or other storage devices.
Network Interface: Equipped with a Network Interface Card (NIC), supporting Ethernet connections, allowing the module to be used for networking applications.
I/O interface: Provides multiple input/output interfaces, including serial port (COM), parallel port (LPT), PS/2 interface, VGA interface, etc., for connecting peripheral devices.
Operating System Support: Typically supports DOS, Windows 3. x, Windows 95, Windows NT, and other operating systems, and can also run certain real-time operating systems (RTOS) or embedded Linux versions.
application area
Industrial automation: As a core component of industrial control systems, it is used for real-time data processing and control tasks.
Embedded system: applied in various embedded devices, such as network terminals, data acquisition systems, industrial computers, etc.
Network computing: Used for early network computing devices, providing basic computing and networking functions.
Factory automation: used as the main controller in factory automation systems to process data and control instructions for various automation equipment.
technical specifications
Processor: Intel 486DX66 processor with a clock speed of 66 MHz.
Memory: SIMM memory modules are usually supported, and the memory capacity depends on the specific model.
Storage: Supports IDE, SCSI and other storage devices, usually with one or more hard disk interfaces.
Expansion Slot: Provides ISA, PCI, and other expansion slots for adding additional functional cards.
Power requirements: Usually standard AT power supply or specific industrial power input.
Size: The physical size of a single board computer is usually the standard 3U or 6U industrial rack installation size.
2.产 品 展 示
