KJ2005X1-MQ1卡件,KJ2005X1-MQ1怎么使用
附录D是NIDI01输入/输出终端的快速参考
分配、跳线设置、电路板布局和电缆连接。参见数字输入端接模块（NIDI01）更多信息说明。
图D-1显示了NIDI01电路板布局和所需的跳线设置。图D-2显示了终端分配
和输入/输出信号极性。图D-3显示了终端电缆
KJ2005X1-MQ1卡件连接。IMHSS03模块可以使用NTDI01数字输入/输出终端单元来终止其输入/输出连接，但只有
IMHSS02功能。NTDI01终端装置没有支持IMHSS03模块的其他功能。终端装置上的Dip分流器配置输入/输出信号。这个IMHSS03模块有四个模拟输入，九个模拟输出，
三个数字输入和一个数字输出终止于NTDI01终端装置。
快速参考附录E是NTDI01输入/输出终端的快速参考分配、双工分流设置、电路板布局和电缆连接。参见数字输入终端装置（NTDI01）说明了解更多信息。图E-1显示了NTDI01电路板布局。表E-1列出分流设置。图E-2显示了终端
The IMHSS03 module can use an NTDI01 Digital I/O Termina
tion Unit to terminate its I/O connections, but will only have
IMHSS02 functionality. The NTDI01 termination unit does not
support the additional features of the IMHSS03 module. Dip
shunts on the termination unit configure the I/O signals. The
IMHSS03 module has four analog inputs, nine analog outputs,
three digital inputs and one digital output that terminate at
the NTDI01 termination unit.
QUICK REFERENCE
Appendix E serves as a quick reference of NTDI01 I/O terminal
assignments, dipshunt settings, circuit board layout and cable
connections. Refer to the Digital Input Termination Unit
(NTDI01) instruction for more information.
Figure E-1 shows the NTDI01 circuit board layout. Table E-1
lists dipshunt settings. Figure E-2 shows the terminal
