BENTLY 3500/70 140471-01脉冲速度监测器   PDF资料

1.产 品 资 料 介 绍：

中文资料：

Bently Nevada 3500/70 140471-01 脉冲速度监测器是 3500 系列机械保护和状态监测系统中的关键组件，专门用于监测旋转设备的速度。它能够检测和分析旋转机械的速度信号，以确保设备在正常操作范围内运行。以下是该监测器的主要特点、功能和应用领域：

主要特点：

1. 高精度监测：能够精确监测旋转机械的速度，提供高分辨率的数据输出。
2. 多通道支持：支持多个独立监测通道，可以同时监测多个速度信号。
3. 模块化设计：便于安装、维护和更换，符合3500系列的标准机架设计。
4. 实时数据处理：内置信号处理能力，能够实时处理和分析输入信号。
5. 兼容性强：与3500系列系统中的其他模块完全兼容，确保系统整体性能和可靠性。

功能：

1. 速度监测：精确测量旋转机械的速度，确保设备在正常操作范围内运行。
2. 报警功能：配置报警阈值，当监测数据超出预设范围时，自动触发报警，提示操作人员进行处理。
3. 数据记录：记录监测数据和事件日志，便于后续分析和诊断。
4. 系统集成：与3500系列其他监测和保护模块无缝集成，提供全面的设备状态监测和保护方案。
5. 灵活配置：通过软件配置，可以灵活设置不同的报警和控制策略，适应不同的应用需求。

应用领域：

1. 发电厂：用于监测和保护汽轮机、发电机等旋转设备的速度，确保设备安全运行。
2. 石油和天然气：在石油和天然气行业中用于监测压缩机、泵等关键设备的速度，防止设备故障。
3. 化工厂：用于监测化工生产中的关键旋转设备，检测速度异常，防止设备损坏和安全事故。
4. 冶金和采矿：在冶金和采矿行业中用于监测大型机械设备的速度，确保设备稳定运行。
5. 海上平台：用于海上石油平台和钻井设备的速度监测，保障海上作业的连续性和安全性。

英文资料：

Bently Nevada 3500/70 140471-01 Pulse Speed Monitor is a critical component of the 3500 series mechanical protection and condition monitoring system, specifically designed to monitor the speed of rotating equipment. It can detect and analyze the speed signal of rotating machinery to ensure that the equipment operates within the normal operating range. The following are the main features, functions, and application areas of the monitor:

Main features:

High precision monitoring: capable of accurately monitoring the speed of rotating machinery and providing high-resolution data output.

Multi channel support: Supports multiple independent monitoring channels and can simultaneously monitor multiple speed signals.

Modular design: easy to install, maintain, and replace, in line with the standard rack design of the 3500 series.

Real time data processing: Built in signal processing capability, capable of real-time processing and analysis of input signals.

Strong compatibility: Fully compatible with other modules in the 3500 series system, ensuring overall system performance and reliability.

Function:

Speed monitoring: Accurately measure the speed of rotating machinery to ensure that the equipment operates within the normal operating range.

Alarm function: Configure alarm thresholds. When monitoring data exceeds the preset range, an alarm will be automatically triggered to prompt operators to take action.

Data recording: Record monitoring data and event logs for subsequent analysis and diagnosis.

System Integration: Seamless integration with other monitoring and protection modules in the 3500 series, providing comprehensive equipment status monitoring and protection solutions.

Flexible configuration: Through software configuration, different alarm and control strategies can be flexibly set to meet different application requirements.

Application areas:

Power plant: used to monitor and protect the speed of rotating equipment such as turbines and generators, ensuring safe operation of the equipment.

Oil and gas: Used in the oil and gas industry to monitor the speed of critical equipment such as compressors and pumps to prevent equipment failure.

Chemical plant: used to monitor key rotating equipment in chemical production, detect abnormal speed, prevent equipment damage and safety accidents.

Metallurgy and Mining: Used in the metallurgy and mining industry to monitor the speed of large mechanical equipment and ensure stable operation of the equipment.

Offshore platform: used for speed monitoring of offshore oil platforms and drilling equipment, ensuring the continuity and safety of offshore operations.

2.产      品      展      示

3.其他产品

Asea SNAT-03驱动控制板

ASEA DSQC215机器人控制板

ASEA SGCP1000脉冲放大器板

4.其他英文产品

 500CIM05 1MRB150077R1B Communication interface module

 500BIO01 1MRB150005R1J inverter control unit

 500PSM03a soft initiator

5.更多库存型号

本篇文章出自瑞昌明盛自动化设备有限公司官网，转载请附上此链接:http://www.jiangxidcs.com

品牌：BENTLY

型号： 3500/70 140471-01脉冲速度监测器

质保：一年

成色：全新/二手

优势产品：ABB、GE、FOXBORO、TRICONEX、BENTLY、A-B、MOTOROLA、HONEYWELL 、SCHNEIDER

                    WOODWARD、EMERSON、RELIANCE、DEIF、NI、XYVOM等

特点：主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。

应用行业：广泛应用于冶金、石油天然气、玻璃制造业、铝业、石油化工、煤矿、造纸印刷、纺织印染、机械、电子制造、汽车制造、烟草、塑胶机械、电力、水利、水处理/环保、市政工程、锅炉供暖、能源、输配电等

快递方式：国内顺丰、德邦、京东快递包邮，按照实际报价货期发货
