Multilin 269PLUS-DO-31电机管理继电器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Multilin 269PLUS-DO-31电机管理继电器是一款先进的电机保护和控制设备，专为电动机的保护、监测和控制而设计。以下是其主要应用领域和特点：
主要应用领域
工业电机保护
- 用于各种工业电动机的保护，包括泵、风机、压缩机和传送带等应用场景。
- 提供过载、过热、短路和接地故障保护，确保电动机的安全运行。
过程控制系统
- 集成到过程控制系统中，实现电动机的自动化控制和保护。
- 适用于石油化工、钢铁、造纸等行业的过程控制系统。
电力公用事业
- 用于电力公用事业中的电动机保护和监测。
- 确保发电厂和变电站中电动机的可靠运行。
水处理和废水处理
- 保护水处理和废水处理设施中的电动机，防止因故障导致的停机和损坏。
- 提供实时监测和诊断功能，提高系统的可靠性和效率。
矿业和金属加工
- 适用于矿业和金属加工行业中的大型电动机保护。
- 提供综合的保护和监测功能，确保设备的长时间稳定运行。
主要特点
全面的保护功能
- 过载保护：防止电动机因过载而损坏。
- 温度保护：通过热敏电阻监测电动机温度，提供过热保护。
- 短路保护：快速检测和响应短路故障。
- 接地故障保护：检测并隔离接地故障，防止设备损坏。
高级监测和诊断
- 实时监测电动机的运行状态和参数，如电流、电压、功率和温度。
- 提供故障诊断和报警功能，帮助维护人员快速识别和解决问题。
易于集成
- 兼容多种通信协议，如Modbus、DNP3等，便于集成到现有的自动化系统中。
- 提供灵活的输入输出接口，支持多种控制和监测需求。
用户友好的界面
- 配备LCD显示屏和按键，便于现场设置和操作。
- 提供基于PC的软件工具，支持远程配置和监控。
坚固耐用
- 设计坚固耐用，适用于恶劣的工业环境。
- 提供长时间可靠运行，减少维护成本和停机时间。
总结
Multilin 269PLUS-DO-31电机管理继电器是一款高性能、多功能的电动机保护和管理设备，广泛应用于各种工业和公用事业领域。其全面的保护功能、先进的监测和诊断能力、易于集成的特点，使其成为确保电动机安全和高效运行的理想选择。
英文资料：
The Multilin 269PLUS-DO-31 motor management relay is an advanced motor protection and control device designed specifically for the protection, monitoring, and control of electric motors. The following are its main application areas and characteristics:
Main application areas
Industrial motor protection
Used for the protection of various industrial motors, including pumps, fans, compressors, and conveyor belts.
Provide overload, overheating, short circuit, and ground fault protection to ensure the safe operation of the motor.
process control system
Integrate into the process control system to achieve automated control and protection of electric motors.
Process control systems suitable for industries such as petrochemicals, steel, and papermaking.
Electric utilities
Used for motor protection and monitoring in power utilities.
Ensure the reliable operation of electric motors in power plants and substations.
Water treatment and wastewater treatment
Protect the electric motors in water and wastewater treatment facilities to prevent downtime and damage caused by malfunctions.
Provide real-time monitoring and diagnostic functions to improve the reliability and efficiency of the system.
Mining and metal processing
Suitable for the protection of large electric motors in the mining and metal processing industries.
Provide comprehensive protection and monitoring functions to ensure the long-term stable operation of the equipment.
main features
Comprehensive protection function
Overload protection: prevents the motor from being damaged due to overload.
Temperature protection: Monitor the temperature of the motor through a thermistor to provide overheating protection.
Short circuit protection: Quickly detect and respond to short circuit faults.
Ground fault protection: detect and isolate ground faults to prevent equipment damage.
Advanced monitoring and diagnosis
Real time monitoring of the operating status and parameters of the electric motor, such as current, voltage, power, and temperature.
Provide fault diagnosis and alarm functions to help maintenance personnel quickly identify and solve problems.
Easy to integrate
Compatible with multiple communication protocols such as Modbus, DNP3, etc., making it easy to integrate into existing automation systems.
Provide flexible input and output interfaces, supporting multiple control and monitoring requirements.
User friendly interface
Equipped with an LCD display screen and buttons for easy on-site setup and operation.
Provide PC based software tools that support remote configuration and monitoring.
durable
Designed to be sturdy and durable, suitable for harsh industrial environments.
Provide long-term reliable operation, reduce maintenance costs and downtime.
summary
The Multilin 269PLUS-DO-31 motor management relay is a high-performance, multifunctional motor protection and management device widely used in various industrial and utility fields. Its comprehensive protection functions, advanced monitoring and diagnostic capabilities, and easy integration make it an ideal choice for ensuring the safe and efficient operation of electric motors.
2.产 品 展 示
3.其他产品
216EA61B HESG448230R1/G digital input module
UNIROL1010 3BHE035301R0001 Excitation controller
5.更多库存型号
| K42HLFK-LNK-NS-00 | S25HA-37F-24-AB-222K-S14-28 | IEMMU21 |
| K32HLLL-LNK-NS-00 | SERVOSTAR-603 | IEPAF01 |
| K33HLHJ-LNK-NS-01 | SV3405-10000 | IEPAS01 |
| K32HRLG-LNK-NS-00 | SR10000-000000 | IEPAS02 |
| K32HRLM-LNK-NS-00 | PSR45A-112 | IEPDF02 |
| K43HRLM-LNK-NS-01 | PSR45-220 | IEPDS01 |
| K32HCHJ-LEK-PF-01 | SS410-10000 | IEPEP01 |
