Multilin MM300-GEHD2CAB电机保护系统 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Multilin MM300-GEHD2CAB 是 GE 的 Multilin 系列中的一款电机保护系统，专门设计用于电机的保护和控制。它集成了各种保护功能、监控能力和通信选项，旨在确保电机的高效和安全运行。以下是关于 Multilin MM300-GEHD2CAB 电机保护系统的详细信息：
主要特性和功能
电机保护功能：
- 过载保护： 实时监控电机的电流，防止过载导致的电机损坏。
- 堵转保护： 在电机启动时检测堵转情况，并提供保护以防止电机损坏。
- 断相保护： 检测电源的断相或不平衡情况，防止电机因断相而受损。
- 过电压/欠电压保护： 保护电机免受电压波动的影响。
- 短路保护： 检测异常电流情况，提供短路保护以防止电机受损。
- 热保护： 通过监控电机的温度，防止电机过热。
监控与诊断：
- 实时监控： 提供实时的电流、电压、功率和其他关键参数的监控。
- 故障诊断： 记录故障事件并提供详细的诊断信息，帮助快速定位和解决问题。
- 数据记录： 存储历史数据和事件记录，便于后续分析和审计。
通信与集成：
- 通信协议： 支持多种工业标准通信协议，如 Modbus RTU、Modbus TCP/IP、DNP3 和 IEC 61850，便于与其他控制系统集成。
- 远程监控： 通过通信接口支持远程访问和监控，简化维护和管理工作。
用户界面：
- 显示屏： 配备 LCD 显示屏，用于实时显示电机的运行状态和参数。
- 操作界面： 友好的用户界面，方便进行设置和调整。
灵活的输入/输出配置：
- 提供多种输入/输出选项，可根据具体应用需求进行配置，确保系统的灵活性和可扩展性。
英文资料：
The Multilin MM300-GEHD2CAB is a motor protection system in GE's Multilin series, specifically designed for motor protection and control. It integrates various protection functions, monitoring capabilities, and communication options to ensure the efficient and safe operation of the motor. The following is detailed information about the Multilin MM300-GEHD2CAB motor protection system:
Main features and functions
Motor protection function:
Overload protection: Real time monitoring of motor current to prevent motor damage caused by overload.
Blocked rotor protection: Detect the situation of blocked rotor during motor start-up and provide protection to prevent motor damage.
Phase failure protection: detects the phase failure or imbalance of the power supply to prevent damage to the motor due to phase failure.
Overvoltage/undervoltage protection: protects the motor from voltage fluctuations.
Short circuit protection: detects abnormal current conditions and provides short circuit protection to prevent motor damage.
Thermal protection: By monitoring the temperature of the motor, it prevents the motor from overheating.
Monitoring and Diagnosis:
Real time monitoring: Provides real-time monitoring of current, voltage, power, and other key parameters.
Fault diagnosis: Record fault events and provide detailed diagnostic information to help quickly locate and solve problems.
Data recording: Store historical data and event records for subsequent analysis and auditing.
Communication and Integration:
Communication Protocol: Supports multiple industrial standard communication protocols, such as Modbus RTU, Modbus TCP/IP, DNP3, and IEC 61850, making it easy to integrate with other control systems.
Remote monitoring: Supports remote access and monitoring through communication interfaces, simplifying maintenance and management work.
User interface:
Display screen: Equipped with an LCD display screen for real-time display of the motor's operating status and parameters.
Operating Interface: A user-friendly interface that facilitates settings and adjustments.
Flexible input/output configuration:
Provide multiple input/output options that can be configured according to specific application requirements, ensuring the flexibility and scalability of the system.
2.产 品 展 示
