Multilin D30E00HCHF8FH6继电器模块

1.产 品 资 料 介 绍：

中文资料：

Multilin D30E00HCHF8FH6 继电器模块是 GE Multilin 系列中的一款继电器模块，主要用于电力系统的保护、控制和监测。以下是该继电器模块的详细信息，包括主要特点、功能和应用领域：

主要特点和功能

1. 保护功能

• 过流保护：监测系统中的电流，防止因过流导致的设备损坏。
• 欠压和过压保护：提供欠压和过压保护，确保设备在正常电压范围内运行。
• 频率保护：监测系统频率，确保其在允许的范围内，防止频率异常影响设备正常工作。

2. 控制功能

• 自动断路器控制：支持自动控制断路器操作，基于实时保护信息进行自动切换。
• 故障隔离：能够自动隔离故障区域，减少对系统其他部分的影响，提高系统的可靠性。

3. 监控与诊断

• 实时监控：提供系统状态的实时监控，包括电流、电压、频率等关键参数。
• 事件记录：记录和存储事件和故障信息，帮助分析和诊断系统问题。
• 波形捕捉：捕捉电气波形数据，进行详细分析和优化保护设置。

4. 通信接口

• 多协议支持：支持多种通信协议，如 Modbus、DNP3、IEC 61850，确保与其他设备和系统的兼容性。
• 接口选项：通常配备多种通信接口（如以太网、RS-232、RS-485），便于数据交换和系统集成。

5. 用户界面

• 显示屏：配备 LCD 显示屏，用于显示系统状态、参数设置和报警信息。
• 配置工具：提供图形化配置工具，简化参数设置和系统管理。

6. 高可靠性

• 工业级设计：符合工业级标准，能够在恶劣环境条件下稳定运行。
• 抗干扰能力：具备抗电磁干扰和抗噪声能力，确保通信和操作的稳定性。

应用领域

1. 变电站

• 设备保护：用于变电站中的设备保护，防止电流、频率或电压异常造成的损坏。
• 自动化控制：集成在变电站的保护系统中，实现自动化控制和故障隔离。

2. 配电系统

• 馈线保护：为配电系统中的馈线提供保护，防止故障引发系统问题。
• 自动化控制：支持自动化控制功能，如故障隔离和恢复，提高系统的可靠性。

3. 工业电力系统

• 设备保护：保护工业电力系统中的关键设备，确保其在正常运行范围内。
• 系统监控：实时监控系统状态，提供详细的数据和诊断信息。

4. 电力传输

• 线路保护：用于电力传输线路的保护，确保线路在运行中的稳定性和可靠性。
• 系统集成：与其他保护和控制系统集成，提供全面的电力系统解决方案。

总结

Multilin D30E00HCHF8FH6 继电器模块是一款高性能的保护和控制组件，具有过流、欠压、过压和频率保护功能。其实时监控、自动控制和通信功能使其在变电站、配电系统、工业电力系统和电力传输领域具有广泛的应用价值。

英文资料：

The Multilin D30E00HCHF8FH6 relay module is a relay module in the GE Multilin series, mainly used for protection, control, and monitoring of power systems. The following is the detailed information of the relay module, including its main features, functions, and application areas:

Main features and functions

Protection function

Overcurrent protection: Monitor the current in the system to prevent equipment damage caused by overcurrent.

Undervoltage and Overvoltage Protection: Provides undervoltage and overvoltage protection to ensure that the equipment operates within the normal voltage range.

Frequency protection: Monitor the system frequency to ensure it is within the allowable range and prevent abnormal frequency from affecting the normal operation of the equipment.

control function

Automatic circuit breaker control: supports automatic control of circuit breaker operation, and automatically switches based on real-time protection information.

Fault isolation: It can automatically isolate the fault area, reduce the impact on other parts of the system, and improve the reliability of the system.

Monitoring and Diagnosis

Real time monitoring: Provides real-time monitoring of system status, including key parameters such as current, voltage, frequency, etc.

Event logging: Record and store event and fault information to assist in analyzing and diagnosing system issues.

Waveform capture: Capture electrical waveform data for detailed analysis and optimization of protection settings.

communication interface

Multi protocol support: Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, ensuring compatibility with other devices and systems.

Interface options: Typically equipped with multiple communication interfaces (such as Ethernet RS-232、RS-485）， Facilitating data exchange and system integration.

user interface

Display screen: equipped with an LCD display screen, used to display system status, parameter settings, and alarm information.

Configuration tool: Provides graphical configuration tools to simplify parameter settings and system management.

high reliability

Industrial grade design: Meets industrial grade standards and can operate stably in harsh environmental conditions.

Anti interference capability: It has the ability to resist electromagnetic interference and noise, ensuring the stability of communication and operation.

application area

transformer substation

Equipment protection: Used for equipment protection in substations to prevent damage caused by abnormal current, frequency, or voltage.

Automated control: integrated into the protection system of the substation to achieve automated control and fault isolation.

Distribution system

Feedline protection: provides protection for feeders in the distribution system to prevent system problems caused by faults.

Automated control: supports automated control functions such as fault isolation and recovery, improving system reliability.

Industrial power system

Equipment protection: Protect critical equipment in industrial power systems to ensure they are within normal operating range.

System monitoring: Real time monitoring of system status, providing detailed data and diagnostic information.

Power transmission

Line protection: used for the protection of power transmission lines, ensuring the stability and reliability of the lines during operation.

System integration: Integrate with other protection and control systems to provide comprehensive power system solutions.

summary

The Multilin D30E00HCHF8FH6 relay module is a high-performance protection and control component with overcurrent, undervoltage, overvoltage, and frequency protection functions. Real time monitoring, automatic control, and communication functions make it widely applicable in substations, distribution systems, industrial power systems, and power transmission fields.
