创建CIP通用消息以传输DPV1命令在RSLogix 5000软件中：
您的MSG（缓存连接）指令数量有限
可以在RSLogix 5000中保持打开（缓存）状态。查看联机帮助以找出局限性。
如果在梯形图逻辑中使用的MSG指令超过16条，建议您禁用消息指令的缓存选项。
对于只需执行一次的消息指令（即DPV1 Init和DPV1 Class 2 Init命令）禁用缓存连接是建议您运行更多缓存连接消息。
MVME6100工控卡件1、从输入/输出选项卡中选择消息指令，并将其放入配置工具概述的梯级中
SST PROFIBUS配置工具可以通过以太网与SST-PB3-CLX-RLL扫描仪。
必须使用以下产品版本：
•固件版本7.27或更高版本
•配置工具版本3.12.1.0或更高版本
•RSLinx驱动程序版本2.2 OEM/Professional或更高版本请参阅第A.1节，安装和配置RSLinx驱动程序，有关配置驱动程序的详细信息。
图18：扫描仪、以太网和配置工具的关系
梯形图代码。
Creating a CIP Generic Message for Transmitting a
DPV1 Command
In the RSLogix 5000 software:
Note
There is limit to the number of MSG (cache connection) instructions you
can leave as opened (cached) in RSLogix 5000. Check the online help to
find the limitations.
If you are using more than 16 MSG instructions in your ladder logic,
we recommend that you disable the cache option for MSG instructions.
For MSG instructions that only have to be executed once (i.e., DPV1 Init
and DPV1 Class 2 Init commands) disabling the cache connection is
recommended so that you can run more cache connection messages.
1. Select the MSG instruction from the Input/Output tab and place it into a rung of Configuration Tool Overview
Through Ethernet, the SST PROFIBUS Configuration Tool can communicate with an
SST-PB3-CLX-RLL scanner.
Note
The following product versions must be used:
• Firmware version 7.27 or higher
• Configuration Tool version 3.12.1.0 or higher
• RSLinx driver version 2.2 OEM/Professional or higher
Note
Refer to Section A.1, Installing and Configuring the RSLinx Driver,
for details on configuring the driver.
Figure 18: Scanner, Ethernet and Configuration Tool Relationship
ladder code
