P0916RH输出模块,FOXBORO使用流程P0916RH
通过指定以下内容来配置网络：
•本地卡-仅默认单选按钮选择。选择串行单选按钮。
•串行-选择此单选按钮进行串行通信。这是到的COM端口连接的串行电缆。
•RSLinx–如果安装了许可的RSLinx，请指定驱动程序名称和机架中的扫描仪模块插槽。有关更多详细信息，请参阅第12.3节，配置RSLinx连接。
P0916RH输出模块•驱动程序名称–设置为通过以太网通信的RSLinx驱动程序的名称使用扫描仪模块
•插槽编号–扫描仪模块在机架中的位置
•RSLinx路径–如果扫描仪位于远程机架中，则这是相关路径。对于更多详细信息，请参阅第12.3节，配置RSLinx连接。
•IP地址-使用以太网设备时1756-ENBT的IP地址和以太网/IP驱动程序。
不支持通过Linx网关驱动程序的远程设备RSLinx Classic Professional/Gateway v2.54或更高版本。
P0916RH输出模块使用1756-ENET时，IP地址字段可以为空以太网TCP/IP通信ControlLogix模块或RSLinx路径包含IP地址。
•站-设置一个唯一的站号，该站号不被网络
•波特率-不会检测到不支持所选波特率的从属设备
5、选择“确定”保存设置。、准备浏览时，选择搜索从属图标。拥有
已检测到按站点地址顺序显示，如图所示：
配置和编程DP
Configure the network by specifying the following:
•
Local Card - Default radio button selection only. Select the Serial radio button.
•
Serial - Select this radio button for serial communication. This is the COM port to
which your serial cable is connected.
•
RSLinx – If you have a licensed RSLinx installed, specify the Driver Name and
the scanner module slot in the rack. For more details, refer to Section 12.3,
Configuring the RSLinx Connection.
•
Driver Name – Name of the RSLinx Driver set up to communicate over Ethernet
with the scanner module
•
Slot Number – location of the scanner module in the rack
•
RSLinx Path – If the scanner is in a remote rack, this is the relevant path. For
more details, refer to Section 12.3, Configuring the RSLinx Connection.
•
IP Address - The IP address of the 1756-ENBT when using the Ethernet Devices
and Ethernet/IP drivers.
Note
Remote Devices via Linx Gateway driver is not supported with the
RSLinx Classic Profession/Gateway v2.54 or higher.
The IP Address field can be left blank when using the 1756-ENET
Ethernet TCP/IP Communications ControlLogix module or when
RSLinx path contains an IP address.
•
Station - Set a unique station number, one not used by any of the slaves on the
network
•
Baud Rate - Slaves that do not support the selected baud rate will not be detected
5.
Select OK to save your settings.
6.
Select the Search for Slave
icon when you are ready to browse. Slaves that have
been detected display in station address order, as shown:
Configuring and Programming the DP
