DSQC679机器人示教器,DSQC679使用流程
系列B代表SST-PB3-CLX-RLL模块。这是默认设置。系列A代表传统SST-PFB-CLX-RLL。
12、本版本是指模块上的背板固件版本。修订版包含主要和次要修订号。“主要”和“次要”的默认值为8和1。这通电时，版本显示在SST-PB3-CLX-RLL LCD显示屏上，并显示在RSLinx中查看RSWho中模块的属性时。
DSQC679机器人示教器电子键控是一种允许在模块的物理模块和软件配置。一致性检查包括检查属性供应商、产品类型、目录号、主要和次要修订。
有三种可用模式：兼容、精确匹配和禁用关键帧。默认值是兼容模式。在兼容模式下，只有在以下情况下，模块的COPN才会成功：
•模块类型、目录号和主要版本必须匹配
•物理模块的次要修订必须等于或大于在软件中指定。如果要使用电子键控的精确匹配选项，所有SST-PB3-CLX-RLL模块和软件中创建的模块的属性必须火柴如果模块的固件稍后升级，则必须更新版本设置使其完全匹配。“禁用键控”选项允许在不执行一致性检查。不建议使用此选项。
Series B represents the SST-PB3-CLX-RLL module. This is the default. Series A represents
the legacy SST-PFB-CLX-RLL.
12. The Revision refers to the backplane firmware version on module. The revision contains a
Major and Minor revision number. The defaults for Major and Minor are 8 and 1.This
revision is displayed on the SST-PB3-CLX-RLL LCD display at power-up and is displayed
in RSLinx when viewing the properties of our module in RSWho.
13. Electronic keying is a feature that allows a consistency check to be done between the
physical module and software configuration of the module. The consistency check involves
checking attributes Vendor, Product Type, Catalog number, Major and Minor Revision.
There are three modes available: Compatible, Exact Match, and Disable Keying. The default
is compatible mode. In compatible mode, a COPN to the module is only successful when:
•
Module type and Catalog Number and Major revision must match
•
The Minor revision of the physical module must be equal to or greater than the one
specified in the software.
If you want to make use of the Exact Match option for the Electronic keying, all of the
attributes of the SST-PB3-CLX-RLL module and the module created in software must
match. If the module’s firmware is upgraded later, the Revision setting must be updated
so that it matches exactly.
The “Disable Keying” option allows a COPN to the module without performing a
consistency check. This option is not recommended.
