WOODWARD 8444-1067数字调速器,8444-1067如何使用
使用附加配置文件
该程序使用RSLogix 5000的15.00、16.03和17.00版本进行了测试。
配置模块时，请确保CLX处于程序模式。
从SST背板通信模块产品CD中，运行SST Profibus进入产品菜单/SST-PB3-CLX-RLL安装背板产品。这将
安装以下组件以配置AOP模块：o SST Profibus配置工具
o固件模块Pfbclx。ss4和pfbclx。默认安装目录为Program
WOODWARD 8444-1067数字调速器o RSLogix 5000 AOP示例梯形图代码。默认安装目录为ProgramControlLogix\AOP
2、从SST背板通信模块产品CD中，选择产品菜单/SST SST-PB3-CLX-RLL并运行罗克韦尔的RSLogix 5000 AOP安装，然后按照说明书
AOP要求SST-PB3-CLX-RLL加载固件模块Pbfclx。ss4 v8.6或更高和Pfbclx。ss3 7.26或更高版本。pfbclx的版本。ss4在通电时显示。
确定pfbclx的版本。ss3，执行中的命令字符串“ver pfbclx.ss3”超级终端。确定pfbclx的版本。ss3或如果您需要升级
固件模块请参阅第8章“升级扫描仪固件”一节。笔记
升级模块固件以支持AOP后，Profibus ID数字将从0x0876更改为0x0C44。此新ID影响模块作为DP从机。如果需要，可以强制模块继续使用
Profibus ID 0x0876，启用名为Legacy\u ID\u 0876的选项在中配置其加载项配置文件时的模块配置选项卡
RSLogix 5000。
Using the Add-on-Profiles
This procedure was tested with versions 15.00, 16.03 and 17.00 of RSLogix 5000.
Note
When you are configuring the Module, ensure that the CLX is in
Program mode.
1.
From the SST Backplane Communication Module Products CD, run the SST Profibus
backplane Products installation by going to Product Menu/SST-PB3-CLX-RLL. This will
install the following components to configure the module for AOP:
o
SST Profibus Configuration Tool
o
Firmware modules Pfbclx.ss4 and pfbclx.ss3. Default install directory is Program
Files\BradCommunications\SST Profibus\Firmware
o
RSLogix 5000 AOP sample ladder code. Default install directory is Program
Files\BradCommunications\SST Profibus\Ladder Sample Codes for
ControlLogix\AOP
2.
From the SST Backplane Communication Module Products CD, select Product Menu/ SST
SST-PB3-CLX-RLL and run Rockwell’s RSLogix 5000 AOP install and follow the
instructions.
3.
AOP requires the SST-PB3-CLX-RLL to be loaded with firmware modules Pbfclx.ss4 v8.6
or higher and Pfbclx.ss3 7.26 or higher. The version of pfbclx.ss4 is displayed at power-up.
To determine the version of pfbclx.ss3, execute the command string “ver pfbclx.ss3” in
HyperTerminal. To determine the version of pfbclx.ss3 or if you need to upgrade the
firmware modules see chapter 8, section Upgrading the Scanner Firmware.
Note
After upgrading firmware on module to support AOP, the Profibus ID
number will change from 0x0876 to 0x0C44. This new ID affects the
module as a DP Slave. If needed, you can force the module to still use
Profibus ID 0x0876 by enabling the option called Legacy_ID_0876 on
the Module Configuration tab when you configure its Add-on-Profile in
RSLogix 5000.
