DEIF PCD2.M110模块,PCD2.M110使用配置手册
信号调节
传感器信号输出前插座SMB和/或z14/z16*，未耦合，防断路和短路，无反应。
通道1− 传感器1 SMB K1
通道2− 传感器2 SMB K2
信号输出−1.−24 V；信号1:1至传感器输入信号精度为f.s.d的±1%。
DEIF PCD2.M110模块频率范围0。。。16千赫(−3 dB）±20%每负载电阻>100 kΩ内阻1 kΩ*取决于跳线设置J2。
动态输出传感器信号的交流部分作为缩放值输出。
通道1− AC1/通道2− AC2 z14/z16*打开−电路和短路−防电路，非−反应性
标称范围0。。。20 Vpp
测量范围与配置的测量范围相对应特征值，最小400 mVpp，最大8000 mVpp精度为f.s.d的±1%。
DEIF PCD2.M110模块频率范围0.1 Hz。。。16千赫(−3 dB）±20%每负载电阻>10 kΩ电源阻抗10 kΩ内阻约为20Ω*取决于跳线设置J2。
按比例的直流输出传感器信号的直流部分（与静态距离传感器/测量值成比例对象）输出为标准直流电压NGL。
通道1− NGL1/通道2− NGL2 z12/d12断路和短路保护，非反应性标称范围0+10 V直流电测量范围根据传感器0 V对应于工作范围的较低值+10 V对应于功的上限值范围精度/分辨率±1%f.s.d./12位每负载电阻>10 kΩ内阻约为50Ω
Signal conditioning
Sensor signal outputs Front sockets SMB and/or z14 / z16*, uncoupled,
open circuit and short circuit proof, non reactive.
Channel 1 − SENS 1 SMB K1
Channel 2 − SENS 2 SMB K2
Signal output
−1 ... −24 V; signal 1:1 to sensor input signal
Precision
±1 % of f.s.d.
Frequency range 0 ... 16 kHz (−3 dB) ±20 %
Per. load resistance > 100 kΩ
Internal resistance 1 kΩ
*Depends on the jumper setting J2.
Dynamic outputs
The AC portion of the sensor signal is output as scaled value.
Channel 1 − AC1 / channel 2 − AC2 z14 / z16* open−circuit and short−circuit proof, non−
reactive
Nominal range 0...20 Vpp
Measuring range Corresponds to the measuring range configured for
the characteristic value, min. 400 mVpp,
max. 8000 mVpp
Precision
±1 % of f.s.d.
Frequency range 0.1 Hz ... 16 kHz (−3 dB) ±20 %
Per. load resistance > 10 kΩ
Source impedance 10 kΩ
Internal resistance Approximately 20 Ω
*Depends on the jumper setting J2.
Scaled d.c. Outputs
The DC portion of the sensor signal (proportional to the static distance sensor / measurement
object) is output as standardized DC voltage NGL.
Channel 1 − NGL1 / channel 2 − NGL2 z12 / d12 open circuit and short circuit proof, non
reactive
Nominal range 0 ... +10 V DC
Measuring range According to the configured operating range of the
sensor
0 V corresponds to the lower value of the work range
+10 V corresponds to the upper value of the work
range
Precision / resolution
±1 % of f.s.d. / 12 Bit
Per. load resistance > 10 kΩ
Internal resistance Approximately 50 Ω
