TRICONEX 4211系统卡件,TRICONEX 4211使用教程
要激活总线终端并将线路“A”和“B”放置在参考上，请插入跳线如图b）所示。图a）显示了停用总线终端和断开的跳线位置参考（交付状态）。原始传感器信号（未滤波，输入−交直流变换器相位输出信号部分）应用于前面板SMB插座，可在J2跳线接通的情况下切换端子z14：连接条的通道1和z16：通道2。
TRICONEX 4211系统卡件,交付时，J2跳线在端子z14和z16上设置传感器信号的动态部分（缩放到输出范围0。。。20 Vss）应用。必须拆下控制器板才能切换信号在连接条上。使用十字头螺丝刀拆下四个十字−有头螺钉，标识为下图中的箭头。小心地将控制器板从主板上拔下，不要倾斜。J2的位置下图中，主bard上的跳线用白色框架标识。要将原始传感器信号切换到端子z14和z16，请按b）所示放置跳线。如果跳线设置如a）所示，则应用传感器信号的动态部分在端子z14和z16上。
To activate the bus terminator and to place lines “A” and “B” on the references, plug the jumpers
as shown in Fig. b). Fig. a) shows the jumper position for deactivated bus termination and open
references (delivery status).The raw sensor signal (unfiltered, in−phase output signal of the converter with AC and DC
portion) applied to the front panel SMB sockets, can be switched over with the J2 jumpers on
terminals z14: channel 1 and z16: channel 2 of the connection strip. As delivered, the J2 jumpers
are set, that on terminals z14 and z16 the dynamic portion of the sensor signal (scaled to output
range 0 ... 20 Vss) is applied. The controller board must be removed in order to switch the signal
on the connection strip.Use a cross head screwdriver to remove the four cross−headed screws, identified with the
arrows, in the following figure.Carefully pull the controller board off the main board without tilting it. The position of the J2
jumpers on the main bard is identified with a white frame in the following figure.To switch the raw sensor signal to terminals z14 and z16 place the jumpers as shown in b).
If the jumpers are set as shown in a) then the dynamic portion of the sensor signal is applied
on terminals z14 and z16.
