NI SCXI-1141 182610D-01工控控制卡件模块
1.产 品 资 料 介 绍：
中文资料：
NI SCXI-1141 是国家仪器（National Instruments, NI）生产的一款模拟输出/数字输入模块，专为工业控制和测量应用设计。以下是关于 NI SCXI-1141 工控控制卡件模块的基本信息和特点：
基本信息
- 制造商: National Instruments (NI)
- 型号: SCXI-1141
- 产品代码: 182610D-01
主要特点
模拟输出通道:
- 4路模拟输出: 提供4个独立的模拟输出通道，每个通道可以输出可调节的模拟电压信号。
数字输入通道:
- 32路数字输入: 提供32个独立的数字输入通道，用于读取和监测数字信号。
信号类型:
- 模拟输出: 可以输出稳定的模拟电压信号，用于控制外部设备或模拟输出测试。
- 数字输入: 用于监测数字信号状态，如开关、传感器等。
精确度和稳定性:
- 高分辨率: 提供高分辨率的模拟输出，确保精确的电压控制和测量。
- 稳定性: 具备良好的温度稳定性和长时间运行稳定性，适用于工业控制环境。
软件支持:
- LabVIEW: 兼容NI LabVIEW软件，提供强大的数据采集、控制和分析功能。
- SCXI驱动程序: 支持NI的SCXI模块驱动程序，简化配置和编程过程。
模块化设计:
- SCXI接口: 设计用于NI SCXI模块化测量系统，便于与其他SCXI模块集成，构建多功能测试和控制系统。
应用领域:
- 工业控制: 在工业自动化系统中用于模拟信号输出和数字信号监测。
- 测试和测量: 用于实验室测试和测量中的模拟输出和数字输入应用。
- 数据采集: 用于数据采集系统中的控制和信号处理。
总结
NI SCXI-1141 工控控制卡件模块是一款多功能的模拟输出/数字输入设备，适用于工业控制和实验室测量应用。通过其模拟输出和数字输入的组合，能够满足复杂的控制和数据采集需求。其与NI LabVIEW和SCXI驱动程序的无缝集成，使其成为工业自动化、测试和测量以及数据采集系统中的理想选择
英文资料
NI SCXI-1141 is an analog output/digital input module produced by National Instruments (NI), designed specifically for industrial control and measurement applications. The following is the basic information and characteristics of the NI SCXI-1141 industrial control card module:
Basic information
Manufacturer: National Instruments (NI)
Model: SCXI-1141
Product code: 182610D-01
main features
Analog output channel:
4 analog outputs: Provide 4 independent analog output channels, each channel can output adjustable analog voltage signals.
Digital input channel:
32 digital inputs: Provides 32 independent digital input channels for reading and monitoring digital signals.
Signal type:
Analog output: It can output stable analog voltage signals for controlling external devices or analog output testing.
Digital input: used to monitor the status of digital signals, such as switches, sensors, etc.
Accuracy and stability:
High resolution: Provides high-resolution analog output to ensure precise voltage control and measurement.
Stability: It has good temperature stability and long-term operation stability, suitable for industrial control environments.
Software support:
LabVIEW: Compatible with NI LabVIEW software, providing powerful data collection, control, and analysis functions.
SCXI driver: SCXI module driver that supports NI, simplifying configuration and programming processes.
Modular design:
SCXI interface: designed for NI SCXI modular measurement system, facilitating integration with other SCXI modules, and building a multifunctional testing and control system.
Application field:
Industrial control: used in industrial automation systems for analog signal output and digital signal monitoring.
Testing and measurement: Used for analog output and digital input applications in laboratory testing and measurement.
Data acquisition: used for control and signal processing in data acquisition systems.
summary
The NI SCXI-1141 Industrial Control Card Module is a multifunctional analog output/digital input device suitable for industrial control and laboratory measurement applications. By combining its analog output and digital input, it can meet complex control and data acquisition needs. Its seamless integration with NI LabVIEW and SCXI drivers makes it an ideal choice for industrial automation, testing and measurement, and data acquisition systems
2.产 品 展 示
3.产 品 展 示
