NI SCXI-1140 放大器模块
1.产 品 资 料 介 绍：
中文资料：
NI SCXI-1140 是国家仪器（National Instruments, NI）生产的一款信号放大器模块，设计用于测量和放大传感器信号，适用于NI的SCXI（Signal Conditioning eXtensions for Instrumentation）模块化测量系统。以下是关于 NI SCXI-1140 放大器模块的基本信息和特点：
基本信息
- 制造商: National Instruments (NI)
- 型号: SCXI-1140
- 产品类型: 信号放大器模块
- 适用平台: NI SCXI 系列模块化测量系统
主要特点
放大器通道数:
- 4个独立放大器通道: 提供4个独立的放大器通道，每个通道能够单独配置和控制。
放大倍数和增益:
- 可编程增益: 每个通道都具有可编程的增益设置，允许用户根据具体应用需求调整放大倍数。
信号类型:
- 模拟信号放大: 专为放大模拟传感器信号设计，如压力、温度、位移等。
精确度和稳定性:
- 高精度放大: 提供高精度的信号放大功能，确保对传感器信号的准确测量。
- 稳定性: 具备良好的温度稳定性和抗干扰能力，适用于各种环境条件下的长时间稳定运行。
软件支持:
- LabVIEW: 兼容NI LabVIEW软件，提供强大的数据采集、分析和控制功能。
- SCXI驱动程序: 支持NI的SCXI模块驱动程序，简化配置和编程过程。
模块化设计:
- SCXI接口: 设计用于NI SCXI模块化测量系统，方便与其他SCXI模块集成，构建多功能测试系统。
应用领域:
- 传感器信号放大: 用于各种传感器信号的放大和处理，如机械位移传感器、压力传感器等。
- 工业自动化: 在工业自动化系统中用于信号调理和数据采集。
- 实验室测量: 在实验室环境中用于科学研究和数据分析。
总结
NI SCXI-1140 放大器模块是一款专业的信号调理设备，适用于各种需要精确信号放大和测量的应用场景。通过其多通道、可编程增益和高精度设计，能够满足复杂的实时数据采集和分析需求。其与NI LabVIEW和SCXI驱动程序的无缝集成，使其成为工业自动化、实验室测量和科学研究中的理想选择。
英文资料
NI SCXI-1140 is a signal amplifier module produced by National Instruments (NI), designed for measuring and amplifying sensor signals, suitable for NI's SCXI (Signal Conditioning eXtensions for Instrumentation) modular measurement system. The following is the basic information and characteristics about the NI SCXI-1140 amplifier module:
Basic information
Manufacturer: National Instruments (NI)
Model: SCXI-1140
Product type: Signal amplifier module
Applicable platform: NI SCXI series modular measurement system
main features
Number of amplifier channels:
4 independent amplifier channels: Provide 4 independent amplifier channels, each channel can be configured and controlled separately.
Magnification factor and gain:
Programmable gain: Each channel has programmable gain settings, allowing users to adjust the amplification factor according to specific application requirements.
Signal type:
Analog signal amplification: designed specifically for amplifying analog sensor signals, such as pressure, temperature, displacement, etc.
Accuracy and stability:
High precision amplification: Provides high-precision signal amplification function to ensure accurate measurement of sensor signals.
Stability: It has good temperature stability and anti-interference ability, suitable for long-term stable operation under various environmental conditions.
Software support:
LabVIEW: Compatible with NI LabVIEW software, providing powerful data collection, analysis, and control functions.
SCXI driver: SCXI module driver that supports NI, simplifying configuration and programming processes.
Modular design:
SCXI interface: designed for NI SCXI modular measurement system, facilitating integration with other SCXI modules and building a multifunctional testing system.
Application field:
Sensor signal amplification: used for amplifying and processing various sensor signals, such as mechanical displacement sensors, pressure sensors, etc.
Industrial automation: Used for signal conditioning and data acquisition in industrial automation systems.
Laboratory measurement: used for scientific research and data analysis in a laboratory environment.
summary
The NI SCXI-1140 amplifier module is a professional signal conditioning device suitable for various application scenarios that require precise signal amplification and measurement. Through its multi-channel, programmable gain, and high-precision design, it can meet complex real-time data acquisition and analysis needs. Its seamless integration with NI LabVIEW and SCXI drivers makes it an ideal choice for industrial automation, laboratory measurement, and scientific research.
2.产 品 展 示
3.产 品 展 示
