TRICONEX 3625卡件,TRICONEX 3625使用范围
UMT 1是一个测量传感器，用于RMS值。UMT 1可以测量
带电流和电压测量输入。主要计算并显示测量值在双线16字符LC显示屏上，以及也可通过模拟输出传输
（可配置为-20至20 mA、0至20 mA或4至20 mA）或至高级控制系统。
电压和电流用于计算实际功率、无功功率和视在功率、功率系数（cosphi）、kWh和kvarh。kWh和
kVarh也可以通过使用脉冲输出。
TRICONEX 3625卡件测量值列表包括测量的o电压§Y形三通：VL1N/VL2N/VL3N
§Delta：VL12/VL23/VL31 o频率fL123
o电流IL1/IL2/IL3·已计算
o平均电压VØL123/Vmin/Vmax
o平均电流IØL123/Imin/Imax
o实际功率PTotal/PL1/PL2/PL3
o无功功率总量
o视在功率Stotal
o功率因数cosφL1
TRICONEX 3625卡件o有功电能kWh正/负
o无功能量kvarhleading/laging
无法通过PC进行远程配置说明：有不同的UMT 1包
从中选择：组件UMT 1/A3·3×真RMS电压传感
·3×真RMS电流感应
·0.5级精度
·3配置。模拟输出（20 mA）
·1配置。千瓦时/千瓦时的脉冲输出
·双线LC显示器
组件UMT 1/A3SU·3×真RMS电压传感
·3×真RMS电流感应·0.5级精度
·3配置。模拟输出（20 mA）
·1配置。千瓦时/千瓦时的脉冲输出
·双线LC显示器
·RS-485/Modbus RTU
组件UMT 1/A6·3×真RMS电压传感
·3×真RMS电流感应·0.5级精度
·6配置。模拟输出（20 mA）
·1配置。千瓦时/千瓦时的脉冲输出
·双线LC显示器
·真RMS感应·0.5级精度
·显示的所有值在LCD上并通过20 mA模拟输出
·前面板可配置1）·微处理器技术用于准确、可重复而且可靠活动·可选接线的配置
单相，三相，或a两者的结合
·RS-485 Modbus
RTU从机表达UL/cUL列出·CE标记
The UMT 1 is a measuring transducer for true
RMS values. The UMT 1 can measure an
electrical three-phase system with current and
voltage measuring inputs. The primary
measured values are calculated and displayed
on the two-line, 16 character LC Display, and
also transmitted by either analog outputs
(configurable as -20 to 20 mA, 0 to 20 mA, or 4
to 20 mA) or a communication interface to a
higher level-control system.
The primary measured values of voltage and
current are used to calculate the values for
real, reactive, and apparent power, power
factor (cosphi), kWh, and kvarh. The kWh and
kVarh can also be transmitted by using an
pulse output.
The list of measured values includes
· Measured
o Voltage
§
Wye: V
L1N / VL2N / VL3N
§ Delta: VL12 / VL23 / VL31
o Frequency fL123
o Current IL1/IL2/IL3
· Calculated
o
Average voltage VØL123 / Vmin / Vmax
o
Average curren
t I
ØL123
/ I
min
/ I
max
o
Real power PTotal
/ PL1
/ P
L2
/ P
L3
o
Reactive power Q
total
o
Apparent power S
total
o
Power factor cosφ
L1
o
Active energy kWh
positive/negative
o
Reactive energy kvarhleading/lagging
1) Remote configuration via PC is not available
DE
SCRIPTION
There are different UMT 1 packages to
choose from:
Package UMT 1/A3
· 3× true RMS voltage sensing
· 3× true RMS current sensing
· Class 0.5 accuracy
· 3 config. analog outputs (20 mA)
· 1 config. pulse output for kWh/kvarh
· Two-line LC display
Package UMT 1/A3SU
· 3× true RMS voltage sensing
· 3× true RMS current sensing
· Class 0.5 accuracy
· 3 config. analog outputs (20 mA)
· 1 config. pulse output for kWh/kvarh
· Two-line LC display
· RS-485/Modbus RTU
Package UMT 1/A6
· 3× true RMS voltage sensing
· 3× true RMS current sensing
· Class 0.5 accuracy
· 6 config. analog outputs (20 mA)
· 1 config. pulse output for kWh/kvarh
· Two-line LC display
·
True RMS sensing
·
Class 0.5 accuracy
·
All values displayed
on LCD and through
20 mA analog output
·
Front panel
configurable1)
·
Microprocessor
technology for
accurate, repeatable
and reliable
operation
·
Optional wiring
configurations for
either single phase,
three phase, or a
combination of both
·
RS-485 Modbus
RTU Slave
communication
·
UL/cUL Listed
·
CE marked
