TRICONEX MP2101底板,MP2101使用方法教程
PI模块没有
提供合计功能
为测量速度而优化
旋转设备。有关脉冲累加，MP2101。
继电器输出模块
3636R和3636T型继电器
输出（RO）模块是非三重模块，用于非关键与不兼容的点“高端”固态输出开关。
例如，与报警器面板接口。继电器输出模块
接收来自主电源的输出信号
TRICONEX MP2101底板
三个通道中每个通道上的处理器。
然后对三组信号进行表决，
投票数据用于驱动
32个独立继电器。
每个输出都有一个环回电路
验证每个
继电器开关独立于负载压力，而持续的诊断测试
单元任何诊断激活失败都会激活故障指示灯，反过来
激活底盘警报。
继电器输出模块随附
常开（NO）触点。它
支持热备盘模块和
需要单独的外部终端
带电缆接口的面板（ETP）
Tricon背板。
The PI module does not
provide a totalization capability—it is
optimized for measuring the speed of
rotation equipment. For pulse totaliza
tion, see Model 3515 on page 38.
Relay Output Module
The Model 3636R and 3636T Relay
Output (RO) Modules are non-tripli
cated modules for use on non-critical
points which are not compatible with
“high-side” solid-state output switches.
An example is interfacing with annun
ciator panels. The Relay Output module
receives output signals from the Main
Processors on each of three channels.
The three sets of signals are then voted,
and the voted data is used to drive the
32 individual relays.
Each output has a loopback circuit
which verifies the operation of each
relay switch independently of the pres
ence of a load, while ongoing diagnos
tics test the operational status of the
module. Failure of any diagnostic acti
vates the Fault indicator, which in turn
activates the chassis alarm.
The Relay Output module comes with
normally open (NO) contacts. It
supports hot-spare modules and
requires a separate external termination
panel (ETP) with a cable interface to
the Tricon backplane.
