MOTOROLA MVME162-213微处理器模块

1.产 品 资 料 介 绍：

中文资料：

MOTOROLA MVME162-213微处理器模块是一款高性能、高可靠性的嵌入式控制器，属于Emerson/Motorola MVME162系列双高VME模块。以下是关于该模块的详细信息和特点：

1. 处理器与内存：
• MVME162-213基于MC68EC040或可选的MC68LC040微处理器，这两款微处理器为系统提供了强大的处理能力。
• 内存方面，该模块提供1MB、4MB或8MB的校验保护DRAM，以及512Kb的SRAM（带电池备份），为系统提供充足的内存资源。
2. 时钟与备份：
• 配备一个TOD时钟（带电池备份），确保时间的准确性和稳定性，在电源中断的情况下也能保持时间信息。
3. 通信接口：
• MVME162-213支持多种I/O接口和通信协议，包括两个串行端口（EIA-232-D和EIA-232-D/EIA-530），以及可选的LAN ethernet收发接口（DMA）和SCSI总线接口（DMA），使数据传输更加高效和灵活。
4. 系统支持：
• 该模块支持多种操作系统，如VxWorks和Linux等，使得MVME162-213能够在不同的应用环境中进行开发和部署，满足各种嵌入式系统和工业自动化应用的需求。
5. 扩展性与开放性：
• MVME162-213遵循开放计算的原则，包括模块化、可扩展性、可移植性和互操作性，使得它在系统集成和扩展方面更加灵活和方便。
6. 工业级设计：
• MOTOROLA MVME162-213通信模块通常采用工业级设计，具有抗振动、抗冲击、耐高温等特性，适用于工业环境中的长期稳定运行。
7. 技术规格（示例）：
• 在一个特定的配置中，MVME162-213可能配备25 MHz MC68LC040微处理器、4 MB DRAM、128 KB SRAM、1 MB Flash Memory等，具体配置可能因型号和应用需求而异。
8. 应用场景：
• MVME162-213在工业自动化和控制应用中具有很高的应用价值，可以满足各种高精度、高稳定性的需求，特别适用于需要高性能微处理器和丰富内存资源的嵌入式系统。

总之，MOTOROLA MVME162-213微处理器模块以其高性能、高可靠性、丰富的功能和灵活的扩展性，成为工业自动化和嵌入式系统领域的优选解决方案。

英文资料

The MOTOROLA MVME162-213 microprocessor module is a high-performance and highly reliable embedded controller, belonging to the Emerson/Motorola MVME162 series dual high VME module. The following is detailed information and features about this module:

Processor and memory:

The MVME162-213 is based on the MC68EC040 or optional MC68LC040 microprocessor, which provide powerful processing power for the system.

In terms of memory, this module provides 1MB, 4MB, or 8MB of checksum protected DRAM, as well as 512Kb of SRAM (with battery backup), providing sufficient memory resources for the system.

Clock and backup:

Equipped with a TOD clock (with battery backup) to ensure the accuracy and stability of time, and to maintain time information even in the event of power interruption.

Communication interface:

MVME162-213 supports multiple I/O interfaces and communication protocols, including two serial ports (EIA-232-D and EIA-232-D/EIA-530), as well as optional LAN Ethernet transceiver interface (DMA) and SCSI-bus interface (DMA), making data transmission more efficient and flexible.

System support:

This module supports multiple operating systems, such as VxWorks and Linux, enabling MVME162-213 to be developed and deployed in different application environments, meeting the needs of various embedded systems and industrial automation applications.

Scalability and Openness:

MVME162-213 follows the principles of open computing, including modularity, scalability, portability, and interoperability, making it more flexible and convenient in system integration and expansion.

Industrial grade design:

The MOTOROLA MVME162-213 communication module typically adopts an industrial grade design, which has characteristics such as vibration resistance, impact resistance, and high temperature resistance, making it suitable for long-term stable operation in industrial environments.

Technical specifications (example):

In a specific configuration, MVME162-213 may be equipped with a 25 MHz MC68LC040 microprocessor, 4 MB DRAM, 128 KB SRAM, 1 MB Flash Memory, etc. The specific configuration may vary depending on the model and application requirements.

Application scenario:

MVME162-213 has high application value in industrial automation and control applications, meeting various high-precision and high stability requirements, especially suitable for embedded systems that require high-performance microprocessors and rich memory resources.

In summary, the MOTOROLA MVME162-213 microprocessor module has become the preferred solution for industrial automation and embedded systems due to its high performance, reliability, rich functionality, and flexible scalability.

2.产      品      展      示

3.产      品      展      示

HONEYWELL 05704-A-0146 DIGITAL

PROSOFT MVI46-MCM COMMUNICATIO

GESADA-1 输入输出模块

KOLLMORGEN CP310250 伺服驱动器

本篇文章出自瑞昌明盛自动化设备有限公司官网，转载请附上此链接:HTTP://WWW.JIANGXIDCS.COM

品牌：MOTOROLA

型号：MVME162-213微处理器模块

质保：一年

成色：全新/二手

优势产品：ABB、GE、FOXBORO、TRICONEX、BENTLY、A-B、MOTOROLA、HONEYWELL 、SCHNEIDER

                    WOODWARD、EMERSON、RELIANCE、DEIF、NI、XYVOM等

特点：主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。

应用行业：广泛应用于冶金、石油天然气、玻璃制造业、铝业、石油化工、煤矿、造纸印刷、纺织印染、机械、电子制造、汽车制造、烟草、塑胶机械、电力、水利、水处理/环保、市政工程、锅炉供暖、能源、输配电等

快递方式：国内顺丰、德邦、京东快递包邮，按照实际报价货期发货
