RELIANCE 57552-4驱动控制器模块
1.产 品 资 料 介 绍：
中文资料：
RELIANCE 57552-4驱动控制器模块是一款由Reliance Electric公司生产的产品，以下是对该模块的详细介绍：
基本信息
- 品牌：RELIANCE
- 型号：57552-4
- 系列：AutoMax PLC
- 零件号：57552-4
主要特点
- 通用性：57552-4是分布式电源系统通用驱动控制器模块（UDC），最初是作为Reliance Electric AutoMax系统的一部分生产的。
- 可编程性：它是一种用户可编程控制系统，使用微处理器实时控制交流和直流驱动器。
- 存储能力：具有256 KB的非易失性读/写闪存、512 KB的易失性SRAM和4 KB的双端口SRAM。
- 连接性：该模块能够使用光纤链路连接到两个不同的PMI，并可以插入AutoMax卡架组件中，仅占用一个插槽。单个机架最多可插入10个UDC模块，意味着单个机架能够控制多达20个驱动器。
- 通信能力：它使用多总线与机架上的处理器模块进行通信。
面板功能
- 面板上有一系列的六个LED指示灯，分别标记为Card OK、OS OK、COMM A OK、DRV A FLT、COM B OK和DRV B FLT。
- 有数字标记为1-3和NO的测试开关，以及数字标记为1-4和COM的仪表端口。
- 有两组com端口，COMM A和COMM B，都标有XMT和RCV。
英文资料
RELIANCE 57552-4 driver controller module is a product produced by Reliance Electric. The following is a detailed introduction to this module:
Basic information
Brand: RELIANCE
Model: 57552-4
Series: AutoMax PLC
Part number: 57552-4
main features
Universality: 57552-4 is a Universal Driver Controller Module (UDC) for distributed power systems, originally produced as part of the Reliance Electric AutoMax system.
Programmability: It is a user programmable control system that uses microprocessors to control AC and DC drives in real-time.
Storage capacity: With 256 KB of non-volatile read/write flash memory, 512 KB of volatile SRAM, and 4 KB of dual port SRAM.
Connectivity: This module can be connected to two different PMIs using fiber optic links and can be inserted into AutoMax card rack components, occupying only one slot. A single rack can accommodate up to 10 UDC modules, which means a single rack can control up to 20 drives.
Communication capability: It uses multiple buses to communicate with processor modules on the rack.
Panel functions
There are a series of six LED indicator lights on the panel, labeled as Card OK, OS OK, COMM A OK, DRV A FLT, COM B OK, and DRV B FLT.
There are test switches labeled with numbers 1-3 and NO, as well as instrument ports labeled with numbers 1-4 and COM.
There are two sets of COM ports, COMM A and COMM B, both labeled with XMT and RCV.
2.产 品 展 示
3.产 品 展 示
