NI SCXI-1600数据采集模块
1.产 品 资 料 介 绍：
中文资料：
NI SCXI-1600数据采集模块是一款功能全面的数据采集设备，以下是对其特点、规格和应用的详细解析：
主要特点
- 高性能数据采集：NI SCXI-1600具有高达352个通道、16位ADC，采样率高达200 kS/s，能够高效、准确地采集模拟信号。
- 全功能控制和数据模块：该模块不仅用于数据采集，还可用作SCXI数字I/O、开关、模拟输入和模拟输出模块的全功能控制和数据模块。
- 易用性：NI SCXI-1600支持即插即用，安装于SCXI机箱中后，可方便地为其他SCXI模块提供时钟、校准和外部数字触发连接。
- 广泛的信号兼容性：能够接收来自其他模块的模拟信号，并通过USB端口进行数字化、放大和传输，兼容多种信号类型，如RTD、热电偶、应变计、电流源和电压等。
- 强大的系统定时控制器：使用National Instruments DAQ-STC作为系统定时控制器，确保数据采集的准确性和稳定性。
规格参数
- 总线类型：SCXI
- 操作系统/对象：支持Windows、实时系统、Linux
- 测量类型：包括电流、温度、热电偶、电压等
- 通道数：32个（模拟输入通道）
- 采样率：最高200 kS/s
- 带宽：10 kHz
- 信号调理：支持0-20 mA电流输入、低通滤波等功能
应用领域
NI SCXI-1600数据采集模块广泛应用于各种需要高精度数据采集和处理的领域，如工业自动化、环境监测、科研实验等。其高采样率、多通道和易用性等特点使其成为工程师和技术人员不可或缺的数据采集工具。
附加信息
- 兼容性：该模块兼容USB，支持供电或热插入USB端口，便于与其他设备连接和集成。
- 校准与监控：前面板配备了LED指示灯，用于监控机箱的V+和V-导轨状态以及数据采集模块的活动和就绪状态。此外，还提供了一个专用的BNC连接器用于校准。
- 软件支持：NI设备使用NIDAQmx驱动软件运行，该软件与多种软件包/应用程序开发环境（如LabVIEW、LabWindows/CVI或Measurement Studio）兼容，方便用户进行数据采集和分析。
综上所述，NI SCXI-1600数据采集模块以其高性能、易用性和广泛的应用领域，成为数据采集领域的一款重要设备。
英文资料
The NI SCXI-1600 data acquisition module is a comprehensive data acquisition device. The following is a detailed analysis of its characteristics, specifications, and applications:
main features
High performance data acquisition: The NI SCXI-1600 has up to 352 channels, 16 bit ADC, and a sampling rate of up to 200 kS/s, enabling efficient and accurate acquisition of analog signals.
Full function control and data module: This module is not only used for data acquisition, but can also be used as a full function control and data module for SCXI digital I/O, switches, analog inputs, and analog outputs.
Usability: The NI SCXI-1600 supports plug and play, and when installed in the SCXI chassis, it can easily provide clock, calibration, and external digital trigger connections for other SCXI modules.
Wide signal compatibility: capable of receiving analog signals from other modules and digitizing, amplifying, and transmitting them through USB ports, compatible with various signal types such as RTD, thermocouple, strain gauge, current source, and voltage.
Powerful system timing controller: Use National Instruments DAQ-STC as the system timing controller to ensure the accuracy and stability of data collection.
Specification parameters
Bus type: SCXI
Operating system/object: Supports Windows, real-time systems Linux
Measurement types: including current, temperature, thermocouple, voltage, etc
Number of channels: 32 (analog input channels)
Sampling rate: up to 200 kS/s
Bandwidth: 10 kHz
Signal conditioning: Supports 0-20 mA current input, low-pass filtering, and other functions
application area
The NI SCXI-1600 data acquisition module is widely used in various fields that require high-precision data acquisition and processing, such as industrial automation, environmental monitoring, scientific research experiments, etc. Its high sampling rate, multi-channel, and ease of use make it an indispensable data collection tool for engineers and technicians.
Additional information
Compatibility: This module is compatible with USB and supports power or hot insertion into USB ports, making it easy to connect and integrate with other devices.
Calibration and monitoring: The front panel is equipped with LED indicator lights to monitor the V+and V - rail status of the chassis, as well as the activity and readiness status of the data acquisition module. In addition, a dedicated BNC connector is provided for calibration.
Software support: NI devices run using NIDAQmx driver software, which is compatible with various software packages/application development environments such as LabVIEW LabWindows/CVI or Measurement Studio compatibility makes it convenient for users to collect and analyze data.
In summary, The NI SCXI-1600 data acquisition module has become an important device in the field of data acquisition due to its high performance, ease of use, and wide range of applications.
