ABSOLUTE MOX12-P3509 B机器人模块,MOX12-P3509 B说明书文档
模块安装在带有接线盒端子或输入/输出端子的输入/输出接线板上
带屏障端子的接线板，可能需要一个辅助接线板来提供
附加接线端子。MOX12-P3509 B机器人模块,对于带线到板连接器的输入/输出接线板，
通常首选外部连接点，尽管有辅助接线板可以使用。。
辅助接线板的所有端子内部连接在一起。辅助设备
带箱式端子的接线板有13个端子，每个端子可容纳一个AWG
#14（平均2.1mm2横截面）至AWG#22（平均0.36mm2横截面）导线，或两根以上导线
至AWG#18（平均横截面0.86mm2）。带屏障端子的辅助接线板
有九个端子，每个端子可容纳一条或两根导线，最高可达AWG#14（平均值
2.1mm2横截面）。
下图显示了如何使用带接线盒端子的辅助接线板
用于连接到带有接线盒端子的输入/输出接线板的电源。ABSOLUTE MOX12-P3509 B机器人模块
Wiring Examples with Auxiliary Terminal Blocks
If the module is installed on an I/O Terminal Block with Box Terminals or an I/O Terminal
Block with Barrier Terminals, an Auxiliary Terminal Block may be required to provide
additional wiring terminals. For the I/O Terminal Block with Wire to Board Connectors,
external connection points are usually be preferred, although an Auxiliary Terminal Block
can be used..
Auxiliary Terminal Blocks have all terminals connected together internally. The Auxiliary
Terminal Block with box terminals has 13 terminals, each of which accommodates one AWG
# 14 (avg 2.1mm2 cross section) to AWG #22 (avg 0.36mm2 cross section) wire, or two wires up
to AWG #18 (avg. 0.86mm2 cross section). The Auxiliary Terminal Block with barrier terminals
has nine terminals, each of which can accommodate one or two wires up to AWG #14 (avg
2.1mm2 cross section).
The following illustration shows how an Auxiliary Terminal Block with Box Terminals can be
used for power connections to an I/O Terminal Block with Box Terminals.
