HONEYWELL CC-TDIL01称重模块,CC-TDIL01说明书文档
辅助接线板可用于为屏蔽提供额外的接线端子。
辅助接线板的所有端子内部连接在一起。HONEYWELL CC-TDIL01辅助设备
带箱式端子的接线板（IC670ACC002）有13个端子；每个可容纳一个
AWG#14（平均横截面2.1mm2）至AWG#22（平均横截面0.36mm2）电线。
这个
带屏障端子的辅助接线板（IC670ACC001）有九个端子；每个can
容纳一条或两根AWG#14（平均横截面2.1mm2）以下的电线。
输入/输出端子板端子分配
带有箱式端子的接线板每个模块有25个端子。每个可容纳一个
AWG#14（平均横截面积2.1mm2）HONEYWELL CC-TDIL01称重模块至AWG#22（平均横截面积0.36mm2）电线，或两根
AWG#18以下的电线（平均横截面0.86mm2）。如果使用外部跳线，则为单线
容量从AWG#14（2.10mm2）降至AWG#16（1.32mm2）。
带有安全栅端子的输入/输出接线板每个模块有18个端子。每个终端
可容纳一条或两根AWG#14（平均横截面2.1mm2）以下的电线。
带连接器的输入/输出接线板每个模块有一个20针公接头。
所有回路端子彼此共用
An Auxiliary Terminal Block can be used to provide additional wiring terminals for the shields.
Auxiliary Terminal Blocks have all terminals connected together internally. The Auxiliary
Terminal Block with box terminals (IC670ACC002) has 13 terminals; each accommodates one
AWG #14 (avg 2.1mm2 cross section) to AWG #22 (avg 0.36mm2 cross section) wire. The
Auxiliary Terminal Block with barrier terminals (IC670ACC001) has nine terminals; each can
accommodate one or two wires up to AWG #14 (avg 2.1mm2 cross section).
I/O Terminal Block Terminal Assignments
An Terminal Block with Box Terminals has 25 terminals per module. Each accommodates one
AWG #14 (avg 2.1mm2 cross section) to AWG #22 (avg 0.36mm2 cross section) wire, or two
wires up to AWG #18 (avg. 0.86mm2 cross section). If an external jumper is used, single-wire
capacity is reduced from AWG #14 (2.10mm2) to AWG #16 (1.32mm2).
An I/O Terminal Block with Barrier Terminals has 18 terminals per module. Each terminal
can accommodate one or two wires up to AWG #14 (avg 2.1mm2 cross section).
An I/O Terminal Block with Connectors has one 20-pin male connector per module.
All Return terminals are common to each other
