HONEYWELL CC-PDIL01隔离模块,CC-PDIL01中文使用说明
8点隔离模拟电压源输出模块（HONEYWELL CC-PDIL01）容纳
四个一组的两个隔离组中的八个电压输出。它提供八个模拟通道
每个通道具有用户可配置缩放的电压输出。
电压源模拟输出24 VDC 5KΩ 最小负载
支持8路输出电压，范围从–10V到+10V，分辨率为14位。
提供的输出超出范围高达约10.25V。
同时使用字和位数据类型。
可现场重新校准或重置为出厂校准。所有校准数据存储在
闪存。
单个通道配置，包括输出范围和缩放参数。
报告低于/超过范围的故障。
HONEYWELL CC-PDIL01隔离模块
电源
8点隔离模拟电压源输出模块需要单独的电源
输出电源。
发光二极管
单个指示器显示模块状态：
ON：正常运行
间歇性闪烁：模块故障
关闭：无背板电源、无用户电源或致命故障。
The 8 Point Isolated Analog Voltage-source Output Module (IC670ALG310) accommodates
eight voltage outputs in two isolated groups of four. It provides eight channels of analog
voltage outputs with user–configurable scaling for each channel.
VOLTAGE SOURCE
ANALOG OUTPUT
24 VDC 5KΩ MIN LOAD
Supports 8 channels of output voltages ranging from –10V to +10V with 14-bit resolution.
Output overrange provided for up to approximately 10.25V.
Uses both word and bit data types.
Can be field-recalibrated or reset to factory calibration. All calibration data is stored in
FLASH memory.
Individual channel configuration including output range and scaling parameters.
Reports Under/Overrange faults.
Power Sources
The 8 Point Isolated Analog Voltage-source Output Module requires a separate source of
power for the outputs.
LEDs
A single indicator shows module status:
ON: normal operation
Intermittent flashing: module fault
OFF: No backplane power, no user power, or fatal fault.
