HONEYWELL CC-PAIM01温度模块,CC-PAIM01中文说明
电源
模块从总线接口单元接收电源，用于自身操作。
需要外部120VAC电源为输入设备供电。模块输入响应
电压水平从0 VAC到132 VAC。HONEYWELL CC-PAIM01
发光二极管通过模块顶部的透明部分可见的单个LED指示开/关
每个输入的状态。
存在背板电源时，PWR LED亮起。
主机接口
该模块的智能处理由总线接口单元或
系统这包括配置输入默认值和故障报告等功能。模块
具有16位（两个字节）的离散输入数据。需要一个总线接口单元来提供此输入
数据传输到主机和/或本地处理器。CC-PAIM01温度模块
Power Sources
The module receives power from the Bus Interface Unit for its own operation.
An external 120VAC supply is needed to power the input devices. Module inputs respond to
voltage levels from 0 VAC to 132 VAC.
LEDs
Individual LEDs, visible through the transparent portion of the module top, indicate the on/off
status of each input. The PWR LED is on when backplane power is present.
Host Interface
Intelligent processing for this module is performed by the Bus Interface Unit or elsewhere in the
system. This includes configuring features such as input defaults and fault reporting. The module
has 16 bits (two bytes) of discrete input data. A Bus Interface Unit is required to provide this input
data to the host and/or local processor.
