TOSHIBA 2N3A3620-B电子模块,2N3A3620-B使用在哪里
安装接线板之间的电缆
在模块的接线板上安装模块之前，先安装端子之间的连接电缆
阻碍。TOSHIBA 2N3A3620-B每个输入/输出接线板都配有一根短连接电缆，如下图所示。一套
连接电缆的编号为IC670ACC001。可选21英寸（0.53
仪表）电缆（IC670CBL002）也可用（每个输入/输出站只能使用一根更长的电缆）。
下图显示了总线接口单元端子之间的基本电缆连接
块和输入/输出端子块。保护标签仍在输入/输出接线板上，
但已移除标签角，以允许接触接线盒电缆接头。
以相同的方式连接输入/输出接线板。接头采用键控，以确保
正确安装。TOSHIBA 2N3A3620-B电子模块
Installing the Cables Between Terminal Blocks
Before installing modules on their terminal blocks, install the connecting cable(s) between terminal
blocks. A short connecting cable, illustrated below, is supplied with each I/O Terminal Block. A set
of connecting cables is available as renewal part number IC670ACC001. Optional 21-inch (0.53
meter) cable (IC670CBL002) is also available (only one longer cable can be used per I/O station).
The illustration below shows the basic cable connection between a Bus Interface Unit terminal
block and an I/O Terminal Block. The protective labels are still in place on the I/O Terminal Block,
but the label corners have been removed to permit access to the Terminal Block cable connectors.
Make connections between I/O Terminal Blocks the same way. The connectors are keyed to assure
proper installation.
