EMBEDDED EPCDFBA#219 B2驱动模块,EPCDFBA#219 B2使用进展
带安全栅端子的输入/输出接线板
带隔离栅端子（目录号IC670CHS001和101）的输入/输出接线板有37个EPCDFBA#219 B2
终端。每个端子可容纳一条或两根AWG#14（平均2.1mm2）以下的电线交叉
带箱式端子的输入/输出接线板
带箱式端子（目录号IC670CHS002和102）的接线板有51个端子，
每个可容纳一个AWG#14（平均2.1mm2
横截面）至AWG#22线（平均
0.36mm2
横截面），或两根AWG#18（平均0.86mm2）以下的电线
横截面）。绝缘的
外部5mm（0.2in）跳线（如Altech#8879）可用于连接相邻点。什么时候
使用外部跳线，导线容量从AWG#14（2.10mm2）减小
)至AWG#16
EMBEDDED EPCDFBA#219 B2驱动模块
（1.32mm2
).
线路板连接器
带连接器的输入/输出接线板（目录号IC670CHS003和103）有两个20针
输入/输出接线的公接头。配对接头为Amp零件号178289-8。这个
为防止错误插入，对接头进行了键控。AMP D-3000系列中的任何镀锡触点
可与连接器一起使用（Amp零件号1-175217-5用于高接触力插座
20-24量规（0.20-0.56mm2
)电线），1-175218-5用于16-20仪表的高接触力插座
（0.56-1.42mm2）
). GE提供包含两个匹配接头外壳和触点的套件
Fanuc零件号IC670ACC003。该套件包含16-20规格导线的销。压接工具是
此套件中未提供。
I/O Terminal Block with Barrier Terminals
The I/O Terminal Block with barrier terminals (catalog number IC670CHS001 and 101) has 37
terminals. Each terminal can accommodate one or two wires up to AWG #14 (avg 2.1mm
2
cross
section).
I/O Terminal Block with Box Terminals
The Terminal Block with box terminals (catalog number IC670CHS002 and 102) has 51 terminals,
each of which accommodates one AWG #14 (avg 2.1mm
2
cross section) to AWG #22 wire (avg
0.36mm
2
cross section), or two wires up to AWG #18 (avg. 0.86mm
2
cross section). An insulated
external 5mm (0.2in) jumper such as Altech #8879 can be used to connect adjacent points. When
an external jumper is used, the wire capacity is reduced from AWG #14 (2.10mm
2
) to AWG #16
(1.32mm
2
).
Wire to Board Connectors
The I/O Terminal Block with Connectors (catalog number IC670CHS003 and 103) has two 20-pin
male connectors for I/O wiring. The mating connector is Amp part number 178289-8. The
connectors are keyed to prevent wrong insertion. Any tin-plated contact in the AMP D-3000 series
can be used with the connector (Amp part number 1-175217-5 for high contact force receptacle for
20-24 gauge (0.20-0.56mm
2
) wires), 1-175218-5 for high contact force receptacle for 16-20 gauge
(0.56-1.42mm
2)
). A kit containing two mating connector housings and contacts is available as GE
Fanuc part number IC670ACC003. The kit contains pins for 16-20 gauge wire. A crimping tool is
not provided in this kit.
