ANYBUS ABDT-PDP模块,ABDT-PDP卡件
输入/输出接线板可安装在任何方向；首选的垂直方向ABDT-PDP 3183203131
接线端子位于左侧，面板安装脚位于右，如下所示。首选的水平方向是接线端子位于
底部和顶部的安装脚。
此图显示了总体
输入/输出端子尺寸块和位置
面板安装螺钉
.31英寸
.79厘米
3.25英寸
8.26厘米
端子打开时的位置
左侧便于布线
现场控制接线板必须安装在35mm x 7.5mm DIN导轨上，该导轨成为
接地系统的组成部分。ANYBUS ABDT-PDP模块DIN导轨表面必须导电。这个
DIN导轨不得涂漆。
DIN导轨应安装在面板上，以增加抗振性。
安装在接线板上和安装在
35mm x 7.5mm DIN导轨为4.0英寸（10.16厘米）。
The I/O Terminal Block can be installed in any orientation; the preferred vertical orientation for
easier wiring installation is with the wiring terminals on the left and the panel-mounting feet on the
right as shown below. The preferred horizontal orientation is with the wiring terminals at the
bottom and the mounting feet at the top.
This diagram shows overall
dimensions of I/O Terminal
Block, and locations for
panel-mounting screws
.31 in
.79cm
3.25in
8.26cm
position with terminals on
left for easier wiring
Field Control terminal blocks must be installed on a 35mm x 7.5mm DIN rail, which becomes an
integral part of the grounding system. The DIN rail finish must be electrically conductive. The
DIN rail must not be painted.
The DIN rail should be mounted on a panel for added vibration resistance.
The overall depth of Field Control modules when mounted on terminal blocks and installed on a
35mm x 7.5mm DIN rail is 4.0 inches (10.16 cm).
